Каталог запасных частей к технике: Geely MK. LF DOOR LOCK & HANDLE

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Позиция на иллюстрации Заводской номер детали Название детали
1018008853 1018008853 LF DOOR LOCK ACTUATOR ASSY
1 1018005293 LEFT DOOR INTERIOR HANDLE ASSY
2 JQ398M85 PLASTIC NUT
3 C TYPE CROSS SLOTTED HEAD SELF-TAPPING SCREW C TYPE CROSS SLOTTED HEAD SELF-TAPPING SCREW
4 1018005289 LF DOOR LOCK ASSY
4 1058005289 LF DOOR LOCK ASSY(W/O LOCK ACTUATOR)
5 INNER HEXAGON FLOWER HEAD SCREW INNER HEXAGON FLOWER HEAD SCREW
6 CROSS SLOTTED HEAD SCREW & PLAIN WASHER ASSY CROSS SLOTTED HEAD SCREW & PLAIN WASHER ASSY
7 C TYPE CROSS SLOTTED HEAD SELF-TAPPING SCREW C TYPE CROSS SLOTTED HEAD SELF-TAPPING SCREW
8 1018004995 DOOR EXTERIOR UNLOCKING HANDLE HOLE COVER
9 1018005039-01 DOOR EXTERIOR UNLOCKING HANDLE ASSY
10 1018005039 LF DOOR EXTERIOR UNLOCKING HANDLE MOUNTING BRACKET ASSY
11 LF DOOR LOCK CYLINDER ASSY LF DOOR LOCK CYLINDER ASSY
12 1018005043 LOCK STRIKER
13 INNER HEXAGON FLOWER HEAD SCREW INNER HEXAGON FLOWER HEAD SCREW
14 1018005283 DOOR EXTERIOR HANDLE FRONT LINER
15 1018005284 DOOR EXTERIOR HANDLE REAR LINER
16 1018003964 KEY ASSY
17 LF DOOR LOCKING CABLE ASSY LF DOOR LOCKING CABLE ASSY
18 FRONT DOOR LOCK INTERIOR LOCKING CABLE ASSY FRONT DOOR LOCK INTERIOR LOCKING CABLE ASSY
19 CABLE CLIP CABLE CLIP
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
