Каталог запасных частей к технике: Geely MK. BRAKE PIPELINE (ABS)
1
2
3
3
4
5
6
7
7
8
9
9
10
11
11
12
12
13
14
14
15
16
17
18
19
20
20
21
22
23
23
24
25
26
27
28
29
30
31
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| BRAKE PIPELINE (ABS) | BRAKE PIPELINE (ABS) | BRAKE PIPELINE (ABS) | |
| 1406141180 | 1406141180 | DUAL-WAY CONNECTING | |
| 1 | 1014001865 | RF BRAKE PIPE ASSY | |
| 2 | 1014001649 | RF BRAKE HOSE ASSY | |
| 3 | L TYPE SPRING CLIP | L TYPE SPRING CLIP | |
| 4 | 1014001950 | COPPER SEALING WASHER | |
| 5 | Q1460625 | HEXAGON HEAD BOLT & PLAIN WASHER ASSY | |
| 6 | 1014001656 | DUAL-WAY CLIP | |
| 7 | 1014003412 | BRAKE MASTER CYLINDER 1# BRAKE PIPE ASSY | |
| 7 | 1014003926 | BRAKE MASTER CYLINDER 1# BRAKE PIPE ASSY | |
| 8 | 1014001863 | BRAKE MASTER CYLINDER 2# BRAKE PIPE ASSY | |
| 9 | 1014001686 | HECU | |
| 9 | 1014003650 | HECU | |
| 10 | 1014001867 | RR BRAKE PIPE ASSY | |
| 11 | 1017009273 | CONNECTING BOLT | |
| 11 | 1014003923 | CONNECTING BOLT | |
| 12 | 1014003924 | ABS RUBBER CUSHION | |
| 12 | 1017009272 | ABS RUBBER CUSHION | |
| 13 | 1014001864 | LF BRAKE PIPE ASSY | |
| 14 | 1014001888 | HECU CONTROL BRACKET ASSY | |
| 14 | 1014003411 | HECU CONTROL BRACKET ASSY | |
| 15 | HEXAGON HEAD BOLT & SPRING WASHER ASSY | HEXAGON HEAD BOLT & SPRING WASHER ASSY. | |
| 16 | 1014001648 | LF BRAKE HOSE ASSY | |
| 17 | Q32006 | HEXAGON FLANGE NUT | |
| 18 | 1014001866 | LR BRAKE PIPE ASSY | |
| 19 | FIVE-WAY CLIP II | FIVE-WAY CLIP II | |
| 20 | 1014001868 | LR BRAKE PIPE ASSYIII | |
| 21 | 1014001869 | RR BRAKE PIPE ASSYIII | |
| 22 | 1014001658 | SEVEN-WAY CLIP | |
| 23 | 1014001765 | BRAKE HOSE CONNECTING BOLT | |
| 24 | 1014001650 | REAR BRAKE HOSE ASSY | |
| 25 | 1014001738 | LR BRAKE PIPE ASSYII | |
| 26 | 1014001739 | RR BRAKE PIPE ASSYII | |
| 27 | 1014001737 | SINGLE-WAY CLIP | |
| 28 | HEXAGON HEAD BOLT & WASHER ASSY | HEXAGON HEAD BOLT & WASHER ASSY. | |
| 29 | RR BRAKE HOSE FIXING PLATE ASSY | RR BRAKE HOSE FIXING PLATE ASSY | |
| 30 | LR BRAKE HOSE FIXING PLATE ASSY | LR BRAKE HOSE FIXING PLATE ASSY | |
| 31 | Q1460620 | HEXAGON HEAD BOLT & PLAIN WASHER ASSY |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
