Каталог запасных частей к технике: Geely FC. RIGHT SIDE WALL ASSY.

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
19
20
20
21
22
23
23
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
50
51
52
53
54
55
56
56
57
57
58
59
60
60
61
62
63
64
65
66
66
67
67
68
68
69
69
70
70
71
Позиция на иллюстрации Заводской номер детали Название детали
1062000470 1062000470 RIGHT SIDE WALL ASSY.
1 1062000225 RIGHT A-PILLAR INNER PLATE LOWER PART ASSY.
2 1062000224 RIGHT A-PILLAR INNER PLATE UPPER PART ASSY.
3 RIGHT A-PILLAR INNER PLATE CONNECTING PLATE RIGHT A-PILLAR INNER PLATE CONNECTING PLATE
4 LOWER GEMEL FIXING PLATE ASSY LOWER GEMEL FIXING PLATE ASSY.
5 FR CHECK FRAME ASSY FR CHECK FRAME ASSY.
6 1062000250 RIGHT A-PILLAR UPPER REINFORCEMENT ASSY.
7 RIGHT SIDE WALL LOWER FRAME REINFORCEMENT ASSY RIGHT SIDE WALL LOWER FRAME REINFORCEMENT ASSY.
8 RIGHT SIDE WALL LOWER FRAME CHECK BRACKET RIGHT SIDE WALL LOWER FRAME CHECK BRACKET
9 RIGHT SIDE WALL LOWER FRAME INNER LINER ASSY RIGHT SIDE WALL LOWER FRAME INNER LINER ASSY.
10 RIGHT SIDE WALL LOWER FRAME INNER LINER FRONT BRACKET RIGHT SIDE WALL LOWER FRAME INNER LINER FRONT BRACKET
11 RIGHT SIDE WALL LOWER FRAME INNER LINER REAR BRACKET RIGHT SIDE WALL LOWER FRAME INNER LINER REAR BRACKET
12 RIGHT SIDE WALL LOWER FRAME INNER LINER RIGHT SIDE WALL LOWER FRAME INNER LINER
13 1062000219 RIGHT TAILLIGHT FIXING PLATE
14 TAILLIGHT UPPER PLATE BRACKET TAILLIGHT UPPER PLATE BRACKET
15 TAILLIGHT SMALL BRACKET TAILLIGHT SMALL BRACKET
16 RIGHT TAILLIGHT UPPER QUARTER RIGHT TAILLIGHT UPPER QUARTER
17 1062000218 RIGHT SIDE WALL OUTER PANEL
18 DOOR RIGHT HOOK FIXING PLATE ASSY DOOR RIGHT HOOK FIXING PLATE ASSY.
19 RR DOOR LOCK HOOK REINFORCEMENT RR DOOR LOCK HOOK REINFORCEMENT
20 RIGHT SIDE WALL UPPER FRAME REINFORCEMENT RIGHT SIDE WALL UPPER FRAME REINFORCEMENT
21 RIGHT SIDE WALL UPPER SIDE PLATE SUB-ASSY RIGHT SIDE WALL UPPER SIDE PLATE SUB-ASSY.
22 1# CROSS MEMBER CONNECTING PLATE 1# CROSS MEMBER CONNECTING PLATE
23 RIGHT CENTER PILLAR INNER PLATE ASSY RIGHT CENTER PILLAR INNER PLATE ASSY.
24 RIGHT CENTER PILLAR OUTER REINFORCEMENT SUB-ASSY RIGHT CENTER PILLAR OUTER REINFORCEMENT SUB-ASSY.
25 RIGHT CENTER PILLAR INNER REINFORCEMENT RIGHT CENTER PILLAR INNER REINFORCEMENT
26 RF SAFETY BELT LOWER ADJUSTABLE PLATE RF SAFETY BELT LOWER ADJUSTABLE PLATE
27 RF SAFETY BELT LOWER FIXING PLATE ASSY RF SAFETY BELT LOWER FIXING PLATE ASSY.
28 RR DOOR CHECK ROD FRAME ASSY RR DOOR CHECK ROD FRAME ASSY.
29 RIGHT TRUNK BOARD SIDE PLATE RIGHT TRUNK BOARD SIDE PLATE
30 RIGHT TRUNK BOARD UPPER PLATE SUB-ASSY RIGHT TRUNK BOARD UPPER PLATE SUB-ASSY.
31 RR PILLAR INNER PLATE ASSY RR PILLAR INNER PLATE ASSY.
32 RR PILLAR QUARTER RR PILLAR QUARTER
33 RIGHT TRUNK BOARD RIGHT TRUNK BOARD
34 RR CROSS MEMBER 3-WAYS CONNECTING PLATE RR CROSS MEMBER 3-WAYS CONNECTING PLATE
35 RR WHEEL INNER FRONT CONNECTING PLATE SUB-ASSY RR WHEEL INNER FRONT CONNECTING PLATE SUB-ASSY.
36 FUEL FILLER PIPE FIXING PLATE ASSY FUEL FILLER PIPE FIXING PLATE ASSY.
37 RIGHT TRUNK BOARD CONNECTING PLATE RIGHT TRUNK BOARD CONNECTING PLATE
38 RIGHT CENTER PILLAR LOWER HINGE SEAT ASSY RIGHT CENTER PILLAR LOWER HINGE SEAT ASSY.
39 REAR SEAT SAFETY BELT FIXING PLATE ASSY REAR SEAT SAFETY BELT FIXING PLATE ASSY.
40 RR SEAT FIXING BRACKET ASSY RR SEAT FIXING BRACKET ASSY.
41 REAR SEAT SIDE SUPPORT BOARD REAR SEAT SIDE SUPPORT BOARD
42 RR WHEEL BRAKE PIPE BRACKET RR WHEEL BRAKE PIPE BRACKET
43 RR SEAT SIDE SUPPORT BOARD ASSY RR SEAT SIDE SUPPORT BOARD ASSY.
44 HINGE SEAT REINFORCEMENT HINGE SEAT REINFORCEMENT
45 RIGHT HINGE SEAT FIXING BOARD RIGHT HINGE SEAT FIXING BOARD
46 RIGHT HINGE SEAT FIXING BOARD REINFORCEMENT ASSY RIGHT HINGE SEAT FIXING BOARD REINFORCEMENT ASSY.
47 RR WHEEL OUTER COVER SUB-ASSY RR WHEEL OUTER COVER SUB-ASSY.
48 RR WHEEL INNER COVER RR WHEEL INNER COVER
49 RR WHEEL INNER QUARTER CONNECTING PLATE RR WHEEL INNER QUARTER CONNECTING PLATE
50 RIGHT SIDE WALL LOWER FRAME REINFORCEMENT ASSY RIGHT SIDE WALL LOWER FRAME REINFORCEMENT ASSY.
51 1062000219 RIGHT TAILLIGHT FIXING PLATE
52 GASOLINE TANK CAP CONTROL CABLE SEAT GASOLINE TANK CAP CONTROL CABLE SEAT
53 RIGHT CENTER PILLAR OUTER REINFORCEMENT ASSY RIGHT CENTER PILLAR OUTER REINFORCEMENT ASSY.
54 RIGHT CENTER PILLAR INNER REINFORCEMENT 1# SUB-ASSY RIGHT CENTER PILLAR INNER REINFORCEMENT 1# SUB-ASSY.
55 RIGHT CENTER PILLAR INNER REINFORCEMENT 2# SUB-ASSY RIGHT CENTER PILLAR INNER REINFORCEMENT 2# SUB-ASSY.
56 RIGHT CENTER PILLAR INNER REINFORCEMENT ASSY RIGHT CENTER PILLAR INNER REINFORCEMENT ASSY.
57 1062000247 RIGHT A-PILLAR INNER REINFORCEMENT PANEL ASSY.
58 RIGHT SIDE WALL INNER REINFORCEMENT ASSY RIGHT SIDE WALL INNER REINFORCEMENT ASSY.
59 RR DOOR LOCK HOOK FIXING PLATE ASSY RR DOOR LOCK HOOK FIXING PLATE ASSY.
60 RIGHT SIDE WALL OUTER PANEL ASSY RIGHT SIDE WALL OUTER PANEL ASSY.
61 RR WHEEL INNER FRONT CONNECTING PLATE RR WHEEL INNER FRONT CONNECTING PLATE
62 RR WHEEL INNER COVER ASSY RR WHEEL INNER COVER ASSY.
63 RIGHT TRUNK BOARD ASSY RIGHT TRUNK BOARD ASSY.
64 RR WHEEL HOUSING ASSY RR WHEEL HOUSING ASSY.
65 RIGHT TRUNK BOARD SUB-ASSY (2) RIGHT TRUNK BOARD SUB-ASSY. (2)
66 RIGHT TRUNK MAINBOARD UPPER PANEL ASSY RIGHT TRUNK MAINBOARD UPPER PANEL ASSY.
67 RIGHT TRUNK BOARD SUB-ASSY (1) RIGHT TRUNK BOARD SUB-ASSY. (1)
68 RR WHEEL COVER ASSY RR WHEEL COVER ASSY.
69 RIGHT SIDE WALL UPPER SIDE PLATE ASSY RIGHT SIDE WALL UPPER SIDE PLATE ASSY.
70 RIGHT A-PILLAR INNER PLATE ASSY RIGHT A-PILLAR INNER PLATE ASSY.
71 RIGHT A-PILLAR INNER PLATE REINFORCEMENT ASSY RIGHT A-PILLAR INNER PLATE REINFORCEMENT ASSY.
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
