Каталог запасных частей к технике: Geely FC. INSTRUMENT PANEL CROSS RAIL ASSY

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано BYD Chevrolet Daewoo Geely Great Wall Hyundai Lifan Tata АЗЛК ВАЗ ГАЗ ЗАЗ ЗИЛ ИЖ ЛуАЗ РАФ УАЗ

Модель Не выбрано Geely CK (2008) Geely FC (2008) Geely MK (2009)

Схема > Не выбрано BODY ASSY. BODY FRAME ASSY. ENGINE COMPARTMENT ASSY. RADIATOR MOUNTING FRAME ASSY. LEFT SIDE WALL ASSY. RIGHT SIDE WALL ASSY. ROOF SKIN ASSY. ROOF SKIN ASSY. (SUNROOF) LF DOOR ASSY. RF DOOR ASSY. LR DOOR ASSY. RR DOOR ASSY. ENGINE HOOD ASSY. TRUNK LID MOUNTING ASSY. RADIATOR CENTER BRACKET ASSY. FRONT BUMPER FRAME ASSY. REAR BUMPER FRAME ASSY. TOOL & ACCESSORY FLOOR TRIM & ACCESSORY INSTRUMENT PANEL ASSY. PILLAR TRIM & ACCESSORY INSTRUMENT PANEL CROSS RAIL ASSY SOUND & HEAT INSULATION RUBBER PLUG TRUNK TRIM & ACCESSORY TRUNK LOCK ASSY. ROOF INTERIOR TRIM & ACCESSORY SAFETY BELT ASSY. LF DOOR TRIM & ACCESSORY LF DOOR LOCK & HANDLE RF DOOR INTERIOR TRIM & ASSECCORY RF DOOR LOCK & HANDLE FRONT DOOR WINDOW ASSY. FRONT DOOR WEATHERSTRIP ASSY. LR DOOR INTERIOR TRIM & ACCESSORY LR DOOR LOCK & HANDLE RR DOOR INTERIOR TRIM & ACCESSORY RR DOOR LOCK & HANDLE REAR DOOR WINDOW ASSY. REAR DOOR WEATHERSTRIP DOOR CHECK DRIVER SEAT ASSY. FRONT SEAT ASSY. REAR SEAT ASSY. FRONT BUMPER REAR BUMPER EMBLEMS FRONT WINDSHIELD REAR WINDSHIELD EXTERIOR TRIM & ACCESSORY REARVIEW MIRROR & ACCESSORY SUNROOF ASSY. ENGINE HOOD LOCK ASSY. ENGINE HOOD INTERIOR TRIM & ACCESSORY ENGINE ASSY. ENGINE MOUNTING ASSY. GASOLINE TANK FUEL PIPELINE AIR INTAKE SYSTEM COOLING SYSTEM EXHAUST SYSTEM CNG ENGINE ASSY. PETROL ENGINE ASSY.(JL4G15) ENGINE RIGHT MOUNTING BRACKET CYLINDER BLOCK ASSY CYLINDER HEAD ASSY. CYLINDER HEAD COMPONENTS CYLINDER HEAD COVER COMPONENTS PISTON CONNECTING ROD COMPONENTS CRANKSHAFT FLYWHEEL COMPONENTS CAMSHAFT ASSY. INTAKE & OUTLET VALVE EXHAUST MANIFOLD ASSY. INTAKE MANIFOLD ASSY. OIL PAN ASSY. OIL STRAINER ASSY. OIL PUMP ASSY. OIL FILTER ASSY. FUEL PUMP ASSY. FUEL INJECTOR ASSY. CANISTER CANISTER ASSY. HEATER INLET & OUTLET PIPE COMPONENTS DRIVE BELT TENSIONER ASSY. WATER PUMP ASSY. CLUTCH ASSY. ALTERNATOR COMPONENTS IGNITION COIL ASSY. STARTER ASSY. ENGINE WIRING HARNESS ECU PETROL ENGINE ASSY.(JL4G18) ENGINE RIGHT MOUNTING BRACKET CYLINDER BLOCK ASSY. CYLINDER HEAD ASSY. CYLINDER HEAD FIXING SUB-ASSY. CYLINDER HEAD COVER COMPONENTS PISTON CONNECTING ROD COMPONENTS CRANKSHAFT FLYWHEEL COMPONENTS CAMSHAFT ASSY. INTAKE & OUTLET VALVE EXHAUST MANIFOLD ASSY. INTAKE MANIFOLD ASSY. OIL PAN ASSY. OIL STRAINER ASSY. OIL PUMP ASSY. OIL FILTER ASSY. FUEL PUMP ASSY. FUEL INJECTOR ASSY CANISTER CANISTER ASSY. HEATER INLET & OUTLET PIPE COMPONENTS DRIVE BELT TENSIONER ASSY. WATER PUMP ASSY. CLUTCH ASSY. ALTERNATOR COMPONENTS IGNITION COIL ASSY. STARTER ASSY. ENGINE WIRING HARNESS ECU S170 TRANSMISSION ASSY. S170 TRANSAXLE ASSY. S170 DIFFERENTIAL ASSY. S170 COVER-GEARSHIFT ASSY. S170 GEARSHIFT SYSTEM ASSY. S170 OUTPUT SHAFT ASSY. S170 SHAFT-INPUT ASSY. FRONT SUSPENSION ASSY. REAR SUSPENSION ASSY. DRIVE SHAFT ASSY. WHEEL ASSY. BRAKE PEDAL ASSY. BRAKE PIPELINE ASSY. FRONT BRAKE WITH STEERING KNUCKLE ASSY. FRONT STEERING KNUCKLE WITH WHEEL HUB ASSY. REAR BRAKE WITH WHEEL HUB ASSY. PARKING BRAKE CONTROL ASSY. STEERING GEAR EPS ASSY. EPS PIPELINE ASSY. STEERING WHEEL ASSY. ACCELERATOR PEDAL ASSY. ELECTRON ACCELERATOR PEDAL CLUTCH PIPELINE ASSY. GEARSHIFT CONTROL ASSY. COMBINATION METER ASSY. ELECTRICITY SWITCH FRONT COMBINATION LAMP ASSY. FRONT FOGLIGHT ASSY. REAR FOGLIGHT ASSY. INTERIOR DOME LAMP REAR COMBINATION LAMP ASSY. LICENSE PLATE LAMP HIGH-MOUNTED BRAKE LAMP ASSY. TRUNK LAMP ASSY. DOOR LAMP ASSY. WIPER ASSY. WASHER ASSY. SOUNDER SYSYTEM LIGHTER ASSY. HORN ASSY. BATTERY & BRACKET ASSY. SRS ASSY. ENGINE COMPARTMENT WIRING HARNESS ASSY. INSTRUMENT PANEL WIRING HARNESS ASSY. DOOR WIRING HARNESS ASSY. REAR WIRING HARNESS ASSY. ABS SYSTEM STARTER WIRE ASSY. FUSE BOX BODY ELECTRIC CONTROL PARKING SENSOR SPEED SENSOR ASSY. CONTROL SYSTEM ASSY. A/C PIPELINE SYSTEM CONDENSER ASSY. HVAC ASSY. A/C VENT PIPE ASSY. COMPRESSOR A/C UNIT CNG SYSTEM

1

2

3

4

5

6

7

8

9

Позиция на иллюстрации	Заводской номер детали		Название детали
1	1068000070		INSTRUMENT PANEL FRAME ASSY.
2	1068000073		I/P FRAME UPPER MOUNTING BRACKET ASSY.
3	1068000074		I/P FRAME LOWER MOUNTING BRACKET ASSY.
4	1068000071		I/P LEFT MOUNTING PLATE ASSY.
5	1068000072		I/P RIGHT MOUNTING PLATE ASSY.
6	HEXAGON FLANGE BOLT M8X16		HEXAGON FLANGE BOLT M8X16
7	HEXAGON NUT & PLAIN WASHER ASSY M6		HEXAGON NUT & PLAIN WASHER ASSY. M6
8	HEXAGON FLANGE NUT M6		HEXAGON FLANGE NUT M6
9	HEXAGON FLANGE NUT M8		HEXAGON FLANGE NUT M8

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
