Каталог запасных частей к технике: Geely FC. BODY ASSY.
1
1
2
3
4
5
5
6
7
7
8
8
9
10
11
12
13
13
13
13
14
14
15
16
16
16
16
16
17
18
19
20
21
22
23
23
24
24
25
26
27
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 10621000202 | BODY ASSY. (SUNROOF) | |
| 1 | 106210000102 | BODY ASSY. | |
| 2 | BODY FRAME ASSY | BODY FRAME ASSY. | |
| 3 | 106200045801 | WING ASSY,LH | |
| 4 | 106200045901 | WING ASSY,RH | |
| 5 | HEXAGON HEAD BOLT & PLAIN WASHER ASSY | HEXAGON HEAD BOLT & PLAIN WASHER ASSY. | |
| 6 | 106200048201 | TRUNK LID ASSY | |
| 7 | 1062000017 | TRUNK LID HINGE ASSY. | |
| 8 | CIRCLIP | CIRCLIP | |
| 9 | 106200047501 | FRONT DOOR ASSY,LH | |
| 10 | 106200047901 | FRONT DOOR ASSY,RH | |
| 11 | 106200047601 | REAR DOOR ASSY,LH | |
| 12 | 106200048001 | REAR DOOR ASSY,RH | |
| 13 | NUT M8X20 | HEXAGON FLANGE NUT M8X20 | |
| 14 | NUT | NUT | |
| 15 | 106200047801 | ENGINE HOOD MOUNTING ASSY. | |
| 16 | BOLT & PLAIN WASHER ASSY | HEXAGON HEAD BOLT & PLAIN WASHER ASSY. | |
| 17 | 106200001501 | OIL FILLER CAP ASSY | |
| 18 | NUT M6X15 | HEXAGON FLANGE NUT M6X15 | |
| 19 | 1061000021 | FIRE EXTINGUISHER MOUNTING BRACKET | |
| 20 | 106200046301 | FRONT BUMPER FRAME ASSY. | |
| 21 | BOLT & PLAIN WASHER ASSY | HEXAGON HEAD BOLT & PLAIN WASHER ASSY. | |
| 22 | 106200046401 | REAR BUMPER FRAME MOUNTING ASSY. | |
| 23 | NUT M10X125 | NUT M10X1.25 | |
| 24 | BOLT & PLAIN WASHER ASSY | HEXAGON HEAD BOLT & PLAIN WASHER ASSY. | |
| 25 | 1062000448 | RADIATOR CENTER BRACKET ASSY. | |
| 26 | BOLT & PLAIN WASHER ASSY | HEXAGON HEAD BOLT & PLAIN WASHER ASSY. | |
| 27 | BOLT & PLAIN WASHER ASSY | HEXAGON HEAD BOLT & PLAIN WASHER ASSY. |
