Каталог запасных частей к технике: Geely CK. RIGHT WALL ASSY

Тип техники

Марка

Модель

Схема

1

2

2

3

4

5

6

7

7

8

9

10

11

12

13

14

15

Позиция на иллюстрации	Заводской номер детали		Название детали
5401022180001	5401022180001		RIGHT WALL ASSY.
1	5401022180001		RIGHT WALL ASSY.
2	1012002708		RIGHT UPPER SIDE RAIL FRONT PART INNER BOARD RIGHT UPPER SIDE RAIL CENERT PART
2	1012002689		INNER BOARD
3	5401360180		REAR BUMPER RIGHT FIXING BRACKET ASSY.
4	WING MOUNTING NUT PLATE ASSY		WING MOUNTING NUT PLATE ASSY.
5	RR DOOR LOCK BUCKLE REINFORCEMENT ASSY		RR DOOR LOCK BUCKLE REINFORCEMENT ASSY.
6	RIGHT UPPER SIDE RAIL INNER BOARD ASSY		RIGHT UPPER SIDE RAIL INNER BOARD ASSY.
7	1012002685		CENTER PILLAR INNER BOARD .RH
7	PILLAR OUTER PANEL		CENTER PILLAR OUTER PANEL REINFORCEMENT ASSY.RH
8	1012002706		RR WHEEL COVER INNER BOARD ASSY.
9	WALL REAR		RIGHT WALL REAR PART INNER BOARD & WHEEL COVER ASSY. RR COMBINATION TAILLIGHT MOUNTING
10	5401720180001		PLATE ASSY.
11	RIGHT PULL SPRING SEAT		RIGHT PULL SPRING SEAT
12	RIGHT DOORFRAME LOWER SIDE RAIL REINFORCEMENT ASSY		RIGHT DOORFRAME LOWER SIDE RAIL REINFORCEMENT ASSY.
13	RF PILLAR OUTER PANEL REINFORCEMENT ASSY		RF PILLAR OUTER PANEL REINFORCEMENT ASSY.
14	106201002601		RF PILLAR INNER BOARD ASSY.
15	RR WALL OUTER PANEL LOWER PART		RR WALL OUTER PANEL LOWER PART

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
