Каталог запасных частей к технике: Geely CK. ENGINE COMPARTMENT ASSY
1
1
1
2
3
4
4
4
5
6
7
7
8
8
8
9
9
9
10
11
11
12
12
12
13
13
13
14
15
15
16
17
18
19
19
19
20
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| ENGINE COMPARTMENT ASSY | ENGINE COMPARTMENT ASSY | ENGINE COMPARTMENT ASSY. | |
| 1 | 8400480171001 | FRONT CROSS MEMBER ASSY. | |
| 1 | 8400480180001 | FRONT CROSS MEMBER ASSY. | |
| 2 | 101200290601 | FRONT CROSS MEMBER RIGHT BOARD | |
| 3 | Q1460820 | HEXAGON HEAD BOLT & WASHER ASSY. | |
| 4 | 8400691180 | ENGINE HOOD LOCK BRACKET ASSY. | |
| 4 | 1208385180 | ENGINE HOOD LOCK BRACKET ASSY. | |
| 5 | 101200290401 | FRONT CROSS MEMBER LEFT BOARD | |
| 6 | JQ146C1030 | HEXAGON HEAD BOLT & WASHER ASSY. | |
| 7 | BRACKET NUT PLATE ASSY | LF COMBINATION HEADLIGHT BRACKET NUT PLATE ASSY. | |
| 8 | SUPPORT BRACKET ASSY | ENGINE HOOD LF SUPPORT BRACKET ASSY. | |
| 9 | SUPPORT SUB-ASSY | ENGINE HOOD LF SUPPORT SUB-ASSY. | |
| 10 | SUPPORT ASSY | ENGINE HOOD LF SUPPORT ASSY. | |
| 11 | BRACKET NUT PLATE ASSY | LF COMBINATION HEADLIGHT BRACKET NUT PLATE ASSY. | |
| 12 | SUPPORT BRACKET ASSY | ENGINE HOOD LF SUPPORT BRACKET ASSY. | |
| 13 | SUPPORT SUB-ASSY | ENGINE HOOD LF SUPPORT SUB-ASSY. | |
| 14 | SUPPORT ASSY | ENGINE HOOD LF SUPPORT ASSY. | |
| 15 | 1018007901 | FRONT CROSS MEMBER UPPER PLATE ASSY. | |
| 16 | FRONT HOOK PLATE | FRONT HOOK PLATE | |
| 17 | 8400040180001 | RF SPLASH GUARD & FRONT SIDE RAIL ASSY. | |
| 18 | 8400030180001 | LF SPLASH GUARD & FRONT SIDE RAIL ASSY. | |
| 19 | 8400480171001 | FRONT CROSS MEMBER ASSY. | |
| 19 | 8400480180001 | FRONT CROSS MEMBER ASSY. | |
| 20 | Q1460820 | HEXAGON HEAD BOLT & WASHER ASSY. |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
