Каталог запасных частей к технике: Tata SFC 407 LHD Euro II. REAR SPRING AND SUSPENSION
1
2
3
4
5
6
7
8
9
11
13
14
15
18
19
20
21
22
23
25
26
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 270532400114 | 270532400114 | ASSY BUMP STOP BRACKET | |
| 265131400112 | 265131400112 | ASSY REAR AXLE STOPPER | |
| 1 | 265132410108 | ASSY. REAR SPRING | |
| 2 | 265132410109 | ASSY. FIRST LEAF WITH BUSH | |
| 3 | 265132417193 | SECOND LEAF | |
| 4 | 265132417194 | THIRD LEAF | |
| 5 | 265132417195 | FOURTH LEAF | |
| 6 | 265132417196 | FIFTH LEAF | |
| 7 | 265132417197 | SIXTH LEAF | |
| 8 | 265132417198 | SEVENTH LEAF | |
| 9 | 265132417199 | EIGHTH LEAF | |
| 11 | 265132403401 | BUSH | |
| 13 | 11084110703 | CENTRE BOLT M 10X110X10 | |
| 14 | NSP | HEX. NUT M 10 | |
| 15 | 265132404227 | SPRING CLIP | |
| 18 | 265132400183 | ASSY. SHACKLE (REAR SPRING) | |
| 19 | 265132407199 | LOCK PLATE | |
| 20 | 265132106704 | SPRING PIN (SHACKLE END) | |
| 21 | 265132400126 | ASSY. SEALING RING | |
| 22 | 17170600801 | GREASE NIPPLE AM 8X1 | |
| 23 | 265132106701 | SPRING PIN | |
| 25 | 265132503701 | GUIDE PLATE REAR SPRING | |
| 26 | 270532504202 | ‘U’ CLAMP REAR |
