Каталог запасных частей к технике: Tata SFC 407 LHD Euro II. GEAR SHAFTS AND GEARS

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
4
4
6
7
7
7
8
8
8
9
9
10
11
11
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
13
13
14
14
14
14
14
14
14
15
17
18
21
24
24
25
25
26
26
26
26
26
26
26
26
27
28
28
30
31
34
36
36
37
38
39
39
39
39
39
39
40
41
44
45
45
45
45
45
46
47
48
50
51
51
52
52
52
52
53
54
54
55
55
56
56
57
58
59
60
Позиция на иллюстрации Заводской номер детали Название детали
CARRIER 4 / 5 CARRIER 4 / 5 CARRIER 4 / 5
251526258201 251526258201 OIL SLINGER (DRIVE SHAFT)
1 251526207904 MAIN SHAFT
2 251526205411 GEAR FIRST SPEED
4 251526203104 NEEDLE CAGE 1ST / 2ND SPEED
6 251526205403 REVERSE GEAR
7 COMP. SPRING COMP. SPRING
8 BALL PIN BALL PIN
9 CARRIER 2 / 3 CARRIER 2 / 3
10 251526203802 SYNCHRONISING CONE
11 251526204604 SHIFTER SLEEVE (1, REVERSE, 2 & 3 SPEED)
12 251526208605 SPACER 6.75 THICK
12 251526208603 SPACER 6.65 THICK
12 251526208619 SPACER 7.45 THICK
12 251526208618 SPACER 7.40 THICK
12 251526208617 SPACER 7.35 THICK
12 251526208616 SPACER 7.30 THICK
12 251526208613 SPACER 7.15 THICK
12 251526208604 SPACER 6.70 THICK
12 251526208606 SPACER 6.80 THICK
12 251526208608 SPACER 6.90 THICK
12 251526208609 SPACER 6.95 THICK
12 251526208610 SPACER 7.00 THICK
12 251526208614 SPACER 7.20 THICK
12 251526208612 SPACER 7.10 THICK
12 251526208611 SPACER 7.05 THICK
13 251526203114 SINGLE ROW DEEP GROOVE BALL BEARING
14 251526204304 SNAP RING 2.78 THICK
14 251526204302 SNAP RING 2.68 THICK
14 251526204303 SNAP RING 2.73 THICK
14 251526204305 SNAP RING 2.83 THICK
14 251526204306 SNAP RING 2.88 THICK
14 251526204307 SNAP RING 2.93 THICK
15 251526200119 ASSY.GEAR SPEEDOMETER DRIVE
17 251526208601 SPACER
18 251526205402 HELICAL GEAR 2ND SPEED
21 251526205407 ENGAGING GEAR (2ND AND 3RD SPEED)
24 CARRIER 1ST CARRIER 1ST
25 251526203803 SYNCHRO CONE (2ND / 3RD)
26 251526204316 CIRCLIP 2.66 THICK
26 251526204312 CIRCLIP 2.5 THICK
26 251526204313 CIRCLIP 2.54 THICK
26 251526204314 CIRCLIP 2.58 THICK
26 251526204315 CIRCLIP 2.62 THICK
26 251526204333 CIRCLIP 2.7 THICK
26 251526204334 CIRCLIP 2.8 THICK
26 251526204335 CIRCLIP 2.75 THICK
27 251526205408 HELICAL GEAR 3RD SPEED
28 251526203103 NEEDLE CAGE (4TH / 3RD SPEED)
30 251526205401 HELICAL GEAR (4TH SPEED)
31 251526203402 COLLOR BUSH (4TH SPEED)
34 251526205410 ENGAGING GEAR 4TH / 5TH SPEED
36 251526203801 SYNCHRONISING CONE (4TH / 5TH SPEED)
37 251526208702 SPRING RING
38 251526204601 SHIFTER SLEEVE (4TH / 5TH SPEED)
39 251526204320 CIRCLIP 2.58 THICK
39 251526204311 CIRCLIP 2.46 THICK
39 251526204318 CIRCLIP 2.5 THICK
39 251526204319 CIRCLIP 2.54 THICK
39 251526204321 CIRCLIP 2.62 THICK
39 251526204322 CIRCLIP 2.66 THICK
40 251526253101 ROLLER CAGE
41 251526257913 DRIVESHAFT (5.54, WITH CIRCLIP GROOVE)
44 251526258602 SPACER DRIVE SHAFT
45 251526254306 CIRCLIP (2.5 THK)
45 251526254307 CIRCLIP (2.4 THK)
45 251526254308 CIRCLIP (2.3 THK)
45 251526254309 CIRCLIP (2.2 THK)
45 251526254310 CIRCLIP (2.1 THK)
46 251526307904 COUNTER SHAFT
47 251526305409 4TH GEAR COUNTER SHAFT
48 251526305408 CONSTANT MESH GEAR (COUNTER SHAFT)
50 14550504007 EXT. CIRCLIP 40X2.5 H
51 265133403129 TAPER ROLLER BEARING
52 3122632152 SHIM 0.050 FOR COUNTER SHAFT
52 3122631652 SHIM 0.500 FOR COUNTER SHAFT
52 3122631552 SHIM 0.240 FOR COUNTER SHAFT
52 3122631452 SHIM 0.125 FOR COUNTER SHAFT
53 251526355402 REVERSE IDLER GEAR
54 251526353101 ROLLER CAGE REVERSE IDLER
55 251526358601 SPACER
56 14580603603 INT. CIRCLIP 36X1.5 N
57 251526357901 REVERSE IDLER GEAR SHAFT
58 251526200111 ASSY. COUPLING FLANGE
59 265141106502 HEX. NUT (M 26X1.5)
60 885426060407 SYNCHRO KIT GBS 18 CONSISTING OF :
