Каталог запасных частей к технике: Tata SFC 407 LHD Euro II. FRONT SPRING AND SUSPENSION
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
14
15
17
18
20
21
22
23
24
25
26
27
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 265132107139 | 265132107139 | PLATE | |
| 1 | 265132100162 | ASSY. FRONT SPRING | |
| 2 | 265132100163 | ASSY. FIRST LEAF WITH BUSH | |
| 3 | 265132403401 | BUSH | |
| 4 | 265132117124 | SECOND LEAF | |
| 5 | 265132117125 | THIRD LEAF | |
| 6 | 265132117126 | FOURTH LEAF | |
| 7 | 265132117127 | FIFTH LEAF | |
| 8 | 265132117128 | SIXTH LEAF | |
| 9 | 265132117129 | SEVENTH LEAF | |
| 10 | 265132117130 | EIGHTH LEAF | |
| 11 | 265132117131 | NINTH LEAF | |
| 12 | 265132404231 | SPRING CLIP | |
| 12 | 265132404230 | SPRING CLIP | |
| 13 | 11084110797 | CENTRE BOLT M10X85X1 | |
| 14 | NSP | HEX. NUT M 10 | |
| 15 | 13300509201 | SNAP HEAD RIVET 10X18 | |
| 17 | 265132106701 | SPRING PIN | |
| 18 | 265132400126 | ASSY. SEALING RING | |
| 20 | 17170600801 | GREASE NIPPLE AM 8X1 | |
| 21 | 265132100146 | ASSY. SHACKLE (FRONT SPRING) | |
| 22 | 265132106704 | SPRING PIN (SHACKLE END) | |
| 23 | 265132107173 | LOCK PLATE | |
| 24 | 270532200101 | ASSY. GUIDE PLATE (FRONT SPRING) | |
| 25 | 265132207704 | RUBBER BUFFER FRONT SPRING | |
| 26 | 265132204204 | ‘U’ CLAMP | |
| 27 | NSP | HEX. NUT M 10 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
