Каталог запасных частей к технике: Tata SFC 407 LHD Euro II. ENGINE TIMING
1
3
4
6
7
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
27
28
29
30
31
32
41
41
41
42
45
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 253405106701 | 253405106701 | CYL.PIN (CAM SHAFT) | |
| 252305113101 | 252305113101 | CAMSHAFT BUSH | |
| 253405990102 | 253405990102 | CAMSHAFT BEARING SET CONSISTING OF : | |
| 3120550653 | 3120550653 | CONNECTING NIPPLE, INNER | |
| 3120550553 | 3120550553 | CONNECTING NIPPLE, OUTER | |
| 1 | 253405100119 | ASSY CAMSHAFT W CYL PIN:NORMAL | |
| 3 | 252707130134 | ASSY CAMSHAFT GEAR AND DRIVE GEAR(FIP) | |
| 4 | 252705115403 | GEAR CAMSHAFT EURO II | |
| 6 | 252505103201 | BOLT (CAM SHAFT GEAR MTG) | |
| 7 | 252707135401 | DRIVE GEAR, FIP EURO II | |
| 11 | 252305105901 | PARALLEL KEY | |
| 12 | 3520510062 | BUTTING RING (TIMER TO CAMSHAFT) | |
| 13 | CAMSHAFT BEARING NO. 1 | CAMSHAFT BEARING NO. 1 | |
| 14 | CAMSHAFT BUSH | CAMSHAFT BUSH | |
| 15 | 3520520762 | THRUST WASHER (CAMSHAFT TO CYL. BLOCK) | |
| 16 | 3129900004 | HEX SCREW (TO THRUST WASHER) | |
| 17 | 253405139902 | VALVE TAPPET | |
| 18 | 253405167901 | PUSH ROD INLET AND EXHAUST | |
| 19 | 252705147902 | ASSY. ROCKER ARM SHAFT | |
| 20 | 17071001407 | SEALING CAP | |
| 21 | 3520501033 | ROCKER ARM LEFT WITH BUSH | |
| 22 | 3120550050 | BUSH | |
| 23 | 252305146701 | BALL END TAPPET ADJUSTER | |
| 24 | 3129900251 | HEX. NUT (BALL PIN) | |
| 25 | 3520500634 | ROCKER ARM RIGHT WITH BUSH | |
| 26 | 3520550610 | ROCKER ARM SUPPORT NO. 1 | |
| 27 | 3520550410 | ROCKER ARM SUPPORT NO. 2, 5, 6 | |
| 28 | 3520550510 | ROCKER ARM SUPPORT NO. 3, 4 | |
| 29 | 11433206101 | GRUB SCREW AM 6X10, (ROCKER ARM SUPPORT TO ROCKER ARM SHAFT) | |
| 30 | 3129930701 | SPRING (LONG) | |
| 31 | 3129930005 | SPRING (SHORT) | |
| 32 | 3129930025 | SPRING CLIP (TO SPRINGS AND ROCKER ARM SHAFT) | |
| 41 | 3120550171 | BOLT (TO ROCKER ARM BRACKETS) | |
| 42 | 11064012632 | HEX. BOLT M 12X75 | |
| 45 | 252705140101 | ASSY. ROCKER ARM SHAFT WITH ARMS |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
