Каталог запасных частей к технике: Tata SFC 407 LHD Euro II. ELECTRICAL EQUIPMENTS 357173
7
8
10
11
12
14
15
16
19
20
21
23
23
27
27
28
28
35
37
37
45
46
47
50
50
50
56
56
57
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 265154500134 | 265154500134 | STOP LIGHT SWITCH | |
| 265154200158 | 265154200158 | ELECTRIC BUZZER | |
| 264154409906 | 264154409906 | HEAD LAMP LEVELLING MOTOR | |
| 264754200113 | 264754200113 | W/H INST.CLUSTER | |
| 7 | 265154100150 | ASSY.BATT. CABLE +VE,[2100 LG.]50MM.SQ. | |
| 8 | 265154100151 | ASSY.BATT.CABLE -VE,[2600 LG] 50MM SQ. | |
| 10 | 264754200109 | INSTRUMENT CLUSTER (1:0.78) | |
| 11 | 264754209902 | FUEL GAUGE | |
| 12 | 264754209903 | TEMP. GAUGE | |
| 14 | 264754209909 | SPEEDOMETER (1:0.78) | |
| 15 | 265154209989 | SPEEDOCABLE JIS 2000 MM | |
| 16 | 269954209908 | WIPER CONTROLLER | |
| 19 | 269954200185 | KIT-HORN CLEARTONE M/S PADMINI. | |
| 20 | 270654200104 | ASSY BRACKET (HORN MTG) | |
| 21 | 284254209916 | RELAY | |
| 23 | 264154400161 | ASSY. HEAD LAMP LH-LHD | |
| 23 | 264154400160 | ASSY. HEAD LAMP RH-LHD | |
| 27 | 265154400197 | ASSY. BLINKER LAMP LH | |
| 27 | 265154400196 | ASSY. BLINKER LAMP RH | |
| 28 | 265454420140 | ASSY SIDE INDICATOR LAMP LH | |
| 28 | 265454420141 | ASSY SIDE INDICATOR LAMP RH | |
| 35 | 265154430117 | ASSY. ENGINE LAMP | |
| 37 | 264154409904 | FIVE CHAMBER TAIL LAMP(12V) LH | |
| 37 | 264154409905 | FIVE CHAMBER TAIL LAMP(12V) RH | |
| 45 | 284254509915 | DOOR SWITCH (REAR) | |
| 46 | 265454510120 | ASSY.COMBI SWITCH | |
| 47 | 264154500114 | IGNITION CUM STEERING LOCK | |
| 50 | 264154506911 | PIANO SWITCH (EXHAUST BRAKE ON) | |
| 50 | 269854506303 | DUMMY PIANO SWITCH COVER | |
| 50 | 269854500111 | HEAD LAMP LEVELLING SWITCH (VERTICAL) | |
| 56 | 282354509918 | FLASHER | |
| 57 | 265454204914 | RELAY (FOR AUXILIARIES) |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
