Каталог запасных частей к технике: Tata SFC 407 LHD Euro II. AIR SUCTION UNIT
1
2
3
3
3
4
4
4
5
6
7
8
8
8
9
9
10
10
11
11
13
14
16
17
24
24
25
26
27
27
28
28
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 885413062534 | 885413062534 | SET CONNECTING ROD BEARING STD, CONSISTING OF : | |
| 885413092534 | 885413092534 | SET CONNECTING ROD BEARING RS 2, CONSISTING OF : | |
| 885413082534 | 885413082534 | SET CONNECTING ROD BEARING RS 1, CONSISTING OF : | |
| 1 | 3211300416 | ASSY. CONNECTING ROD (AIR COMPRESSOR) | |
| 2 | 885413102534 | SET CONNECTING ROD BUSH STD | |
| 3 | CONNECTING ROD BEARING UPPER RS2 | CONNECTING ROD BEARING UPPER RS2 | |
| 3 | CONNECTING ROD BEARING UPPER RS1 | CONNECTING ROD BEARING UPPER RS1 | |
| 3 | CONNECTING ROD BEARING UPPER STD | CONNECTING ROD BEARING UPPER STD | |
| 4 | CONNECTING ROD BEARING LOWER RS1 | CONNECTING ROD BEARING LOWER RS1 | |
| 4 | CONNECTING ROD BEARING LOWER STD | CONNECTING ROD BEARING LOWER STD | |
| 4 | CONNECTING ROD BEARING LOWER RS2 | CONNECTING ROD BEARING LOWER RS2 | |
| 5 | 3211310171 | GUIDE SCREW, CON. ROD | |
| 6 | 3129900251 | HEX. NUT (BALL PIN) | |
| 7 | 252313140124 | ASSY PISTON AIR COMPRESSOR | |
| 8 | COMPRESSION RING (GR. I & II) | COMPRESSION RING (GR. I & II) | |
| 8 | COMPRESSION RING (GR. I & II) | COMPRESSION RING (GR. I & II) | |
| 9 | NOSE SCRAPER RING GR. III | NOSE SCRAPER RING GR. III | |
| 9 | SCRAPPER RING NORMAL | SCRAPPER RING NORMAL | |
| 10 | OIL RING GR. IV NORMAL | OIL RING GR. IV NORMAL | |
| 10 | OIL RING GR. IV NORMAL | OIL RING GR. IV NORMAL | |
| 11 | 253413990101 | SET AC PISTON RINGS 70 DIA STD | |
| 11 | 252313140127 | SET AC PISTON RINGS 70 DIA STD | |
| 13 | 252313103710 | CYLINDER SLEEVE NORMAL | |
| 14 | 252713105312 | GASKET (0.5 THK) | |
| 16 | 3529900604 | HEX. HEAD COLLAR BOLT | |
| 17 | 253313100102 | ASSY.CYLINDER HEAD AIR SUCTION UNIT | |
| 24 | 252313105301 | GASKET | |
| 24 | 3121310179 | GASKET | |
| 25 | 253413106802 | REDUCER | |
| 26 | 253413100103 | ASSY. OIL LINE | |
| 27 | 16531999049 | PIPE UNION BOLT 10 | |
| 28 | 16220510216 | SEALING WASHER 14X18 AL |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
