Каталог запасных частей к технике: Tata LPT 613 LHD EURO II. INTERNAL AND EXTERNAL FITMENTS
21
22
23
23
26
27
28
29
30
31
32
32
33
34
35
35
37
37
38
38
40
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 264188806301 | 264188806301 | BEADING [FRONT PANEL] | |
| 264181103802 | 264181103802 | BRACKET TOP RH.(R.V.M.) | |
| 264181103801 | 264181103801 | BRACKET TOP LH. (R.V.M.) | |
| 264181103804 | 264181103804 | BRACKET BOTTOM RH.(R.V.M.) | |
| 264181103803 | 264181103803 | BRACKET BOTTOM LH.(R.V.M.) | |
| 264181106330 | 264181106330 | RUBBER PAD(BRACKET TOP R.V.M) | |
| 265172506316 | 265172506316 | GRAB HANDLE (ON DOOR) | |
| 264181106331 | 264181106331 | RUBBER PAD(BRACKET BOTTOM R.V.M) | |
| 264181106332 | 264181106332 | SLEEVE(FOR FRAME R.V.M) | |
| 264181106322 | 264181106322 | INNER BEADING | |
| 264181106321 | 264181106321 | BEADING (FIRE WALL) | |
| 264181106323 | 264181106323 | BOTTOM BEADING (CENTRE FLAP) | |
| 265181006304 | 265181006304 | ASSY. LETTER 'T' | |
| 265181006305 | 265181006305 | ASSY. LETTER 'A' | |
| 264181900114 | 264181900114 | ASSY. COVER BAZZLE LH | |
| 264181900115 | 264181900115 | ASSY. COVER BAZZLE RH | |
| 264181100108 | 264181100108 | LID FUEL PRIMING | |
| 265166400105 | 265166400105 | ASSY KNOB (LID FUEL PRIMING) | |
| 21 | 264181906302 | CENTRE GRILL (FRONT) | |
| 22 | 264181900127 | ‘T’ EMBLEM OVAL STYLISED | |
| 23 | 264181900101 | ASSY. BAZZLE RH | |
| 23 | 264181900102 | ASSY. BAZZLE LH | |
| 26 | 264181900150 | ASSY. COVER SIDE LH (CENTER FLAP) | |
| 27 | 264181900151 | ASSY. COVER SIDE RH (CENTER FLAP) | |
| 28 | 264181900159 | ASSY. COVER CENTRE (WITH TATA LETTERS) | |
| 29 | 264181906332 | GRILL LH | |
| 30 | 264181906333 | GRILL RH | |
| 31 | 264181906331 | GRILL MIDDLE | |
| 32 | 215381106901 | GRAB HANDLE LH | |
| 32 | 215381106902 | GRAB HANDLE RH | |
| 33 | 264181100175 | ASSY. COVER LH (CENTRE FLAP HINGE) | |
| 34 | 264181100176 | ASSY. COVER RH (CENTRE FLAP HINGE) | |
| 35 | 257581100101 | ASSY.SUNVISOR RH | |
| 35 | 257581100102 | ASSY.SUNVISOR LH | |
| 37 | 257681100152 | REAR VIEW MIRROR OUTSIDE RH | |
| 37 | 257681100153 | REAR VIEW MIRROR OUTSIDE LH | |
| 38 | 264181100139 | ASSY, FRAME COMPLETE RH | |
| 38 | 264181100138 | ASSY, FRAME COMPLETE LH | |
| 40 | 264181900122 | "ASSY, MASCOT ""613""" |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
