Каталог запасных частей к технике: Tata LPT 613 LHD EURO II. GEAR BOX HOUSING

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
6
7
11
11
12
15
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
17
18
19
19
20
21
23
23
23
23
23
27
27
30
31
31
32
33
37
38
39
40
41
42
43
44
45
46
47
48
49
54
55
56
57
58
59
60
61
62
63
63
63
64
64
64
65
66
67
68
68
69
70
73
74
75
76
77
78
79
83
Позиция на иллюстрации Заводской номер детали Название детали
250526258201 250526258201 OIL SLINGER (FRONT COVER)
3212610333 3212610333 COVER (FOR PTO APPLICATION)
250526405303 250526405303 GASKET (FOR COVER)
250526713407 250526713407 STOPPER PIECE CHECK PLATE
250526713403 250526713403 SUPPORT PIECE CHECK PLATE
250526000101 250526000101 GEAR BOX GASKET KIT CONSISTING OF :
885426051613 885426051613 OVERHAULING KIT - GB 40 CONSISTING OF :
OIL SEAL OIL SEAL OIL SEAL
OIL SEAL OIL SEAL OIL SEAL
SHIM SHIM SHIM
SHIM SHIM SHIM
SHIM SHIM SHIM
SHIM SHIM SHIM
SHIM SHIM SHIM
GASKET GASKET GASKET
GASKET GASKET GASKET
GASKET GASKET GASKET
GASKET GASKET GASKET
HEX COLLAR NUT HEX COLLAR NUT HEX COLLAR NUT
HEX NUT HEX NUT HEX NUT
PRESSURE SPRING PRESSURE SPRING PRESSURE SPRING
PIN MAIN SHAFT PIN MAIN SHAFT PIN MAIN SHAFT
1 250526040180 ASSY GBS 40-5/6.34,W/6BCF,PTO PROVISION .FR.COMP
2 250526103724 GEAR BOX HOUSING (6.34 RATIO)
3 13050909209 CYLINDRICAL PIN 10 H 8X20
4 0009970006J PLUG OIL FILLING
5 250626107203 MAGNETIC DRAIN PLUG (HEX HEAD TYPE)
6 250530145301 GASKET, FRONT COVER LOWER
6 GASKET FRONT COVER LOWER GASKET FRONT COVER LOWER
7 250530144701 FRONT COVER LOWER
11 250526255301 GASKET (FR. COVER TOP TO HSG.)
11 GASKET FRONT COVERUPPER GASKET FRONT COVERUPPER
12 250530134701 GEAR BOX HOUSING COVER FRONT TOP
15 250526257808 OIL SEAL
16 250530138601 BUTTING RING 2.90 MM THICK
16 250526258601 BUTTING RING 2.95 MM THICK
16 250530138602 BUTTING RING 3.00 MM THICK
16 250526258602 BUTTING RING 3.05 MM THICK
16 250530138603 BUTTING RING 3.10 MM THICK
16 250526258603 BUTTING RING 3.15 MM THICK
16 250530138604 BUTTING RING 3.20 MM THICK
16 250526258604 BUTTING RING 3.25 MM THICK
16 250530138605 BUTTING RING 3.30 MM THICK
16 250526258605 BUTTING RING 3.35 MM THICK
16 250530138606 BUTTING RING 3.40 MM THICK
16 250526258606 BUTTING RING 3.45 MM THICK
16 250530138607 BUTTING RING 3.50 MM THICK
16 250530138608 BUTTING RING 3.60 MM THICK
17 250530153701 GEAR CASE COVER REAR
18 250526207803 OIL SEAL
19 3212610031 ADAPTER
20 3212600086 ASSY. THREADED BUSH
21 1532640055 PLUG SPEEDO DRIVE
23 3122831752 SHIM 0.05 MM THICK
23 3122831052 SHIM 0.1 MM THICK
23 3122831152 SHIM 0.2 MM THICK
23 3122831252 SHIM 0.4 MM THICK
23 3122832152 SHIM 0.8 MM THICK
27 3522610780 GASKET (GEAR CASE COVER REAR)
27 GASKET REAR COVER GASKET REAR COVER
30 250526713755 GEAR CASE COVER TOP (LOWER HALF)
31 250530145301 GASKET, FRONT COVER LOWER
31 GASKET TOP COVER GASKET TOP COVER
32 250530128801 STUD
33 250526716701 PIN SWING LEVER
37 266835150102 PRESSURE RELIEF VALVE
38 250530116701 THRUST PIN (REVERSE INDICATOR SWITCH)
39 3129934201 PRESSURE SPRING (REVERSE INDICATOR SWITCH)
40 265454500134 REVERSE INDICATOR SWITCH
41 250526705105 SWING LEVER - 1ST SPEED
42 250530129201 WASHER (SWING LEVER)
43 250526713409 PRESSURE PIECE FOR CHECK PLATE
44 250526718702 PRESSURE SPRING FOR PRESSURE PIECE
45 3219970103 SLOTTED PLUG
46 250526713410 INTERLOCKING PIN
47 3219930601 PRESSURE SPRING FOR INTERLOCKING PIN
48 16082502401 SEALING PLUG M 24X1.5
49 3212600846 ASSY. CHECK PLATE
54 3212650805 SELECTOR SHAFT FOR FIRST SPEED
55 3212651805 SELECTOR SHAFT (2/3)
56 3212651905 SELECTOR SHAFT (4/5)
57 3222650305 SELECTOR SHAFT (FOR REVERSE GEAR)
58 3222650123 GEAR SHIFT DOG (FOR FIRST GEAR)
59 3212651202 SELECTOR FORK (2/3)
60 250526515102 SELECTOR FORK (4/5)
61 3212651301 SELECTOR FORK (FOR 1ST SPEED GEAR)
62 250526515101 SELECTOR FORK (FOR REVERSE GEAR)
63 3129931001 PRESSURE SPRING
64 15950101102 STEEL BALL 11 MM DIA.
65 3122651036 CLAMP (SELECTOR SHAFT TO GEAR BOX HOUSING)
66 3129940332 LOCKING PLATE (SELECTOR SHAFT TO GEAR BOX HOUSING) TOP COVER
67 250526713756 COVER TOP (UPPER HALF)
68 250726713105 NEEDLE BEARING
69 250526705104 SHIFTER FINGER
70 250526707909 SELECTOR & SHIFTER SHAFT
73 17061602518 OIL SEAL
74 250726717803 SCRAPER RING
75 250726706013 ASSY. SHIFTING LEVER
76 250526718222 CAP
77 250526717701 BELLOW
78 14270202501 HOSE CLIP 25
79 250626715301 GASKET (BETWEEN UPPER & LOWER HALF)
83 3212650849 SLIDING KEY GASKET KIT
