Каталог запасных частей к технике: Tata LPT 613 Euro-III. FUEL INJECTION EQUIPMENT
1
2
3
4
7
10
11
12
13
14
15
16
26
27
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 254707129201 | 254707129201 | HARDENED WASHER EURO II | |
| 13650505063 | 13650505063 | WOODRUFF KEY 4X6.5 | |
| 252707125301 | 252707125301 | GASKET (FOR SUPPORT INJ.PUMP):EURO II KIT H.P.LINES (ROTARY FIP) | |
| 252507145802 | 252507145802 | HOSE (REDUCER FOR LEAKAGE):L=300MM | |
| 0120700066J | 0120700066J | ASSY. CLAMP LOWER | |
| 0120780085J | 0120780085J | CLAMP UPPER | |
| 1 | 252507120147 | ASSY. FIP (ROTARY) EURO III | |
| 2 | 252707123702 | SUPPORT(FOR FUEL INJECTION PUMP):E-III | |
| 3 | 252707135402 | INJECTION PUMP GEAR EURO II | |
| 4 | 252707125302 | GASKET, SUPPORT EURO II | |
| 7 | 252507123302 | REAR SUPPORT BRACKET(FIP TO BLOCK)E-III | |
| 10 | 252507140167 | KIT H.P.LINES (ROTARY FIP) | |
| 11 | HIGH PRESSURE LINE 1ST CYL. | HIGH PRESSURE LINE 1ST CYL. | |
| 12 | HIGH PRESSURE LINE 2ND CYL. | HIGH PRESSURE LINE 2ND CYL. | |
| 13 | HIGH PRESSURE LINE 3RD CYL. | HIGH PRESSURE LINE 3RD CYL. | |
| 14 | HIGH PRESSURE LINE 4TH CYL. | HIGH PRESSURE LINE 4TH CYL. | |
| 15 | HIGH PRESSURE LINE 5TH CYL. | HIGH PRESSURE LINE 5TH CYL. | |
| 16 | HIGH PRESSURE LINE 6TH CYL. | HIGH PRESSURE LINE 6TH CYL. | |
| 26 | 252007144203 | SEAL CLAMP | |
| 27 | 252007148001 | HOLLOW SCREW |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
