Каталог запасных частей к технике: Tata LPT 613 Euro-III. CLUTCH AND BRAKE CONTROL
1
2
2
2
3
3
3
4
7
8
8
8
9
10
11
12
23
24
25
26
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 264129200115 | 264129200115 | MINOR REPAIR KIT, CLUTCH BOOSTER | |
| 264129200114 | 264129200114 | MAJOR REPAIR KIT, CLUTCH BOOSTER | |
| 264129100156 | 264129100156 | MINOR REPAIR KIT CLUTCH MASTER CYLINDER | |
| RUBBER BELLOW | RUBBER BELLOW | RUBBER BELLOW | |
| CIRCLIP | CIRCLIP | CIRCLIP | |
| FORK | FORK | FORK | |
| PUSH ROD | PUSH ROD | PUSH ROD | |
| SEAL | SEAL | SEAL | |
| CRIMPING SLEEVE | CRIMPING SLEEVE | CRIMPING SLEEVE | |
| MINOR REPAIR KIT CLUTCH MASTER CYLINDER | MINOR REPAIR KIT CLUTCH MASTER CYLINDER | MINOR REPAIR KIT CLUTCH MASTER CYLINDER | |
| 264129100155 | 264129100155 | MAJOR REPAIR KIT CLUTCH MASTER CYLINDER, CONSISTING OF : | |
| 264129109902 | 264129109902 | SLEEVE | |
| 1 | 264129200109 | ASSY.CLUTCH PEDAL | |
| 2 | 265129103401 | SINTERED BUSH | |
| 2 | 265129103401 | SINTERED BUSH | |
| 3 | 265129107703 | RUBBER COVER | |
| 3 | 265129107703 | RUBBER COVER | |
| 4 | 264129200107 | ASSY.SUPPORT COMPLETE(CLUTCH) | |
| 7 | 264129108602 | SPACER | |
| 8 | 264129108701 | TORSION SPRING | |
| 8 | 264129108701 | TORSION SPRING | |
| 9 | 264129100117 | ASSY. CLUTCH MASTER CYL. | |
| 10 | 264129106702 | PIN CLUTCH PEDAL | |
| 11 | 264129106301 | BUSH (CLUTCH PEDAL) | |
| 12 | 264129200112 | ASSY. CLUTCH BOOSTER(90DIA) | |
| 23 | 264129200113 | ASSY.BRACKET (CLUTCH BOOSTER MTG.) | |
| 24 | 264129300104 | ASSY. PUSH ROD BRAKE PEDAL | |
| 25 | 264329100135 | ASSY. BRAKE PEDAL COMPLETE, LHD | |
| 26 | 264129106703 | BRAKE PIN | |
| 29 | 264129200110 | ASSY. COVER (CONTROLS) | |
| 30 | 263243700165 | FOOT BRAKE VALVE VOSS 74.5MM |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
