Каталог запасных частей к технике: Tata LPT 613/34 WB Euro III. FRONT SPRING
1
1
2
2
3
3
7
7
35
36
37
38
41
45
46
46
48
49
51
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| FRONT SPRING | FRONT SPRING | FRONT SPRING , DRIVER SIDE (LPT 613) | |
| 17170600801 | 17170600801 | GREASE NIPPLE AM 8X1 | |
| 264032108201 | 264032108201 | LOCKING PLATE | |
| 1 | 264132100133 | ASSY. FRONT SPRING (NORMAL CAMBER) | |
| 1 | 264132100134 | ASSY. FRONT SPRING (HIGHER CAMBER) | |
| 2 | 264132100137 | ASSY. FIRST LEAF WITH BUSH | |
| 2 | 264132100138 | ASSY. FIRST LEAF WITH BUSHES | |
| 3 | 265132403401 | BUSH | |
| 3 | 265132403401 | BUSH | |
| 7 | 264132107195 | SECOND LEAF ASSY FRONT SPRING, (HIGHER CAMBER) | |
| 7 | 264132107206 | SECOND LEAF | |
| 35 | 264032100105 | ASSY. SHACKLE WITH BUSH | |
| 36 | 265132403401 | BUSH | |
| 37 | 265132106704 | SPRING PIN (SHACKLE END) | |
| 38 | 265132400126 | ASSY. SEALING RING | |
| 41 | 257441109902 | GREASE NIPPLE | |
| 45 | 264032207702 | RUBBER BUFFER (FRONT) | |
| 46 | 12052396067 | HEX NUT M 16X1.5 | |
| 48 | 264132207103 | CASTER PLATE | |
| 49 | 264132204209 | U - CLAMP (FRONT) | |
| 51 | 206033105301 | GUIDE PLATE (CAST) FRONT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
