Каталог запасных частей к технике: Tata LPT 1618 TC/52. MAIN SHAFT AND GEAR

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
5
5
5
5
6
6
6
7
7
7
8
8
8
9
9
9
9
9
12
13
15
16
16
16
16
16
16
16
16
16
16
16
16
16
16
16
17
17
17
18
19
19
19
19
19
19
19
19
19
19
19
19
19
20
23
24
25
29
30
33
34
35
41
42
43
43
43
43
43
46
47
48
48
49
51
52
53
55
56
56
56
56
56
56
56
56
58
Позиция на иллюстрации Заводской номер детали Название детали
1 269126207911 MAIN SHAFT (6 SPEED)
2 269126205437 2ND SPEED GEAR[M/SHAFT](LOOSESYN.RING)
3 269126203120 NEEDLE CAGE DOUBLE ROW
4 269126204641 ENGAGING GEAR(1ST/2ND) LOOSE SYN.RING.
5 269126204650 SYNCHROCONE (1/2 -3/4) (CARBON)
5 269126204650 SYNCHROCONE (1/2 -3/4) (CARBON)
6 250726208705 COMPRESSION SPRING
6 250726208705 COMPRESSION SPRING
7 250726206702 RETENTION PIN
7 250726206702 RETENTION PIN
8 269126204618 SHIFTER SLEEVE (1ST / 2ND / 3RD / 4TH)
8 269126204618 SHIFTER SLEEVE (1ST / 2ND / 3RD / 4TH)
9 269126204313 CIRCLIP (2.3 THICK)
9 269126204314 CIRCLIP (2.4 THICK)
9 269126204315 CIRCLIP (2.6 THICK)
9 269126204316 CIRCLIP (2.6 THICK)
9 269126204317 CIRCLIP (2.7 THICK)
12 269126205436 1ST SPEED GEAR[M/SHAFT](LOOSE SYN.RING)
13 269126203111 NEEDLE CAGE 1ST SPEED
15 269126204616 ENGAGING GEAR (REVERSE)
16 269126204301 CIRCLIP (1.8 THICK)
16 269126204302 CIRCLIP (1.9 THICK)
16 269126204304 CIRCLIP (2.1 THICK)
16 269126204305 CIRCLIP (2.2 THICK)
16 269126204310 CIRCLIP (2.3 THICK)
16 269126204311 CIRCLIP (2.4 THICK)
16 269126204303 CIRCLIP (2.0 THICK)
16 269126204301 CIRCLIP (1.8 THICK)
16 269126204302 CIRCLIP (1.9 THICK)
16 269126204303 CIRCLIP (2.0 THICK)
16 269126204304 CIRCLIP (2.1 THICK)
16 269126204305 CIRCLIP (2.2 THICK)
16 269126204310 CIRCLIP (2.3 THICK)
16 269126204311 CIRCLIP (2.4 THICK)
17 269126203106 NEEDLE CAGE (REVERSE / 4TH GEAR)
17 269126203106 NEEDLE CAGE (REVERSE / 4TH GEAR)
18 269126205413 REVERSE GEAR (MAIN SHAFT)
19 269126208614 SPACER (MAIN SHAFT) (11.2 THICK)
19 269126208612 SPACER (MAIN SHAFT) (11.4 THICK)
19 269126208613 SPACER (MAIN SHAFT) (11.3 THICK)
19 269126208627 SPACER (MAIN SHAFT) (10.4 THICK)
19 269126208626 SPACER (MAIN SHAFT) (10.5 THICK)
19 269126208625 SPACER (MAIN SHAFT) (11.5 THICK)
19 269126208624 SPACER (MAIN SHAFT) (11.6 THICK)
19 269126208620 SPACER (MAIN SHAFT) (10.5 THICK)
19 269126208619 SPACER (MAIN SHAFT) (10.7 THICK)
19 269126208618 SPACER (MAIN SHAFT) (10.8 THICK)
19 269126208617 SPACER (MAIN SHAFT) (10.9 THICK)
19 269126208616 SPACER (MAIN SHAFT) (11.0 THICK)
19 269126208615 SPACER (MAIN SHAFT) (11.1 THICK)
20 269126203103 TAPER ROLLER BEARING (CLUTCH SIDE)
23 268826205407 SPEEDO GEAR (MAIN SHAFT)
24 269126208601 SPACER (COUPLING FLANGE)
25 269126207814 OIL SEAL (MAIN SHAFT)
29 269126200173 ASSY. COUPLING FLANGE
30 268826206501 LOCK NUT (COUPLING FLANGE)
33 269126205438 3RD SPEED GEAR[M/SHAFT](LOOSE SYN.RING)
34 269126203124 NEEDLE CAGE (1ST / 2ND / 3RD GEAR)
35 269126204642 ENGAGING GEAR(3RD/4TH) LOOSE SYN.RING.
41 269126205442 4TH SPEED GEAR(6.58 RATIO-LOOSE SYNRING)
42 269126208628 SPACER (MAIN SHAFT)
43 269126204306 CIRCLIP (2.4 THICK)
43 269126204307 CIRCLIP (2.5 THICK)
43 269126204308 CIRCLIP (2.6 THICK)
43 269126204309 CIRCLIP (2.7 THICK)
43 269126204312 CIRCLIP (2.8 THICK)
46 269126200171 ASSY ENGAGING GEAR(5TH/DS)
47 269126203105 NEEDLE CAGE
48 269126204651 SYNCHRO CONE (5 / 6 CARBON)
49 269126204640 ENGAGING GEAR (5TH / 6TH SPEED)
51 268826209901 CARRIER
52 3219930701 COMPRESSION SPRING
53 268826206702 RETENTION PIN (3/4)
55 268826204608 SHIFTER SLEEVE (5TH / 6TH SPEED)
56 251526204312 CIRCLIP 2.5 THICK
56 251526204313 CIRCLIP 2.54 THICK
56 251526204314 CIRCLIP 2.58 THICK
56 251526204315 CIRCLIP 2.62 THICK
56 251526204316 CIRCLIP 2.66 THICK
56 251526204333 CIRCLIP 2.7 THICK
56 251526204334 CIRCLIP 2.8 THICK
56 251526204335 CIRCLIP 2.75 THICK
58 269126253113 ROLLER (FOR DRIVE SHAFT)
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
