Каталог запасных частей к технике: Tata LPT 1618 TC/52. DASH BOARD (TILT CAB)
1
2
2
4
5
6
8
12
13
16
19
21
26
27
31
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 274768900119 | 274768900119 | ASSY DASHBOARD COMPLETE -LHD, GRAY | |
| 264168906370 | 264168906370 | GARNISH (SIDE DEFROST) | |
| 265183106336 | 265183106336 | ELBOW DUCT (FOR VENT NOZZLE) | |
| 264168900186 | 264168900186 | ASSY BRACKET (AIR DISTRIBUTOR TO VENT) | |
| 264168900131 | 264168900131 | ASSY. REINFORCEMENT INSIDE (GLOVE BOX) | |
| 1 | 274768906309 | DASHBOARD (CENTRE) | |
| 2 | 264168900129 | ASSY. REINFORCEMENT MIDDLE RH | |
| 2 | 264168900128 | ASSY. REINFORCEMENT MIDDLE LH | |
| 4 | 274768906347 | DASHBOARD LH | |
| 5 | 264168906373 | DASHBOARD RH (GREY) | |
| 6 | 274768908205 | REINFORCEMENT (FRONT) | |
| 8 | 264168900132 | ASSY. REINFORCEMENT OUTSIDE (GLOVE BOX) | |
| 12 | 264168900135 | ASSY. REINFORCEMENT TOP | |
| 13 | 264168900147 | ASSY. BRACKET LH | |
| 16 | 264168900195 | ASSY. GLOVE BOX (GREY) | |
| 19 | 274768908206 | INSTRUMENT PANEL | |
| 21 | 274768900101 | SET OF NACELLE | |
| 26 | 264168900113 | ASSY. BRACKET LH | |
| 27 | 264168900114 | ASSY. BRACKET RH | |
| 31 | 264168906357 | COVER CLUTCH FLUID BOTTLE |
