Каталог запасных частей к технике: Tata LPT 1618 TC/52. AC AND HEATING SYSTEM
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 274783400115 | 274783400115 | ASSY BRACKET HVAC MTG. ON CR MEMBER | |
| 269854709902 | 269854709902 | DUAL PRESSURE SWITCH | |
| 274783300101 | 274783300101 | ASSY.H.V.A.C. CONTROL COMPLETE | |
| 264183100134 | 264183100134 | ASSY DUCT (HVAC TO DEFROST) | |
| 274783108203 | 274783108203 | BRACKET CONDENSER MTG.(FOOT STEP VERTICAL) | |
| 274783108202 | 274783108202 | BRACKET CONDENSER MTG.(FOOT STEP | |
| 274783108201 | 274783108201 | BRACKET CONDENSER MTG.(CR MEMBER) | |
| 264168900188 | 264168900188 | ASSY BRACKET (REAR DEFROST) | |
| 265183100166 | 265183100166 | ASSY.DEFROST DUCT COMPLETE | |
| 269883406308 | 269883406308 | GROMMET FOR DRAIN HOSE | |
| 269883406307 | 269883406307 | GROMMET FOR HEATER PIPES ON FIRE WALL | |
| 267883400117 | 267883400117 | ASSY WATER VALVE | |
| 274783400117 | 274783400117 | ASSY BRACKET HVAC MTG. ON FIRE WALL | |
| 274783400116 | 274783400116 | ASSY BRACKET HVAC MTG. ON TUNNEL | |
| 269883500104 | 269883500104 | ASSY HEATER DAMPER | |
| 269883400180 | 269883400180 | ASSY. AIR DISTRIBUTION BOX | |
| 269668900108 | 269668900108 | ASSY VENT HOSE | |
| 269883406312 | 269883406312 | HOSE DRAIN HVAC UNIT | |
| 269883410187 | 269883410187 | ASSY.THERMOSTAT | |
| 269883410186 | 269883410186 | ASSY BLOCK VALVE COMPLETE | |
| 274783500102 | 274783500102 | RUBBER HOSE(HEATER INLET) | |
| 274783500103 | 274783500103 | HOSE(THERMOSTATE TO WATER VALVE) | |
| 274783500104 | 274783500104 | RUBBER HOSE (HEATER OUTLET) | |
| 274783300101 | 274783300101 | ASSY.H.V.A.C. CONTROL COMPLETE | |
| 274783400114 | 274783400114 | ASSY. FRESH AIR VALVE (WITH DAMPER) | |
| 6 | 274783400121 | ASSY.H.V.A.C. UNIT COMPLETE | |
| 7 | 269883406313 | HOUSING H.V.A.C. UNIT | |
| 8 | 269883400181 | ASSY. BLOWER WITH RIS | |
| 9 | 269883400182 | ASSY. BLOWER MOTOR | |
| 10 | 269883410190 | ASSY. EVAPORATOR COIL | |
| 11 | 269883500107 | ASSY HEATER COIL | |
| 12 | 274783400122 | ASSY.CONDENSER COMPL. | |
| 13 | 274783400108 | ASSY.CONDENSER SHROUD WITH FAN | |
| 14 | 269883410118 | ASSY.TANK RECEIVER DRIER | |
| 15 | 274783400109 | ASSY. RECEIVER DRIER MTG.BRACKET | |
| 16 | 274783400110 | ASSY HOSE SUCTION | |
| 17 | 274783400111 | ASSY HOSE DISCHARGE | |
| 18 | 274783400112 | ASSY TUBE LIQUID RD INLET | |
| 19 | 264183500114 | ASSY TUBE LIQUID RD OUTLET | |
| 20 | 265183106336 | ELBOW DUCT (FOR VENT NOZZLE) | |
| 21 | 264168910103 | ASSY VENTILATION NOZZLE |
