Каталог запасных частей к технике: Tata LP/LPT 613 LHD. POWER STEERING PIPELINES
2
3
4
5
6
7
8
9
10
10
11
12
13
14
15
16
17
18
18
19
20
20
21
22
25
26
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2574 4680 58 02 | 2574 4680 58 02 | 3/4In LP Hose (620 Mm Approx. Long) | |
| 1428 050030 6 | 1428 050030 6 | Hose Clamp 30 | |
| 2705 4680 58 01 | 2705 4680 58 01 | Rubber Hose | |
| 2 | 2601 4680 58 01 | 3/4 In L.P.Hose (300 Mm Approx. Long) | |
| 3 | 1428 050035 7 | Hose Clamp 35 | |
| 4 | 2641 4680 01 15 | Assy Tube (Tank To Pump) | |
| 5 | 2576 4680 68 03 | Elbow | |
| 6 | 1205 610260 2 | Lock Nut M26X1.5 | |
| 7 | 2574 4350 92 01 | Sealing Ring | |
| 8 | 1705 050120 5 | O Ring 25.0X2.65 | |
| 9 | 2641 4680 68 05 | Banjo Body | |
| 10 | 2641 4680 68 06 | Banjo | |
| 11 | 1622 071024 0 | Sealing Washer 16x20 Cu | |
| 12 | 2651 4480 01 01 | 3/8 Inch High Pressure Hose Assy | |
| 13 | 1642 080150 9 | Coupling Body L15 | |
| 14 | 2641 4680 01 13 | Assy Tube | |
| 15 | 2573 4410 68 02 | Banjo Body | |
| 16 | 2573 4410 68 03 | Banjo | |
| 17 | 1622 071024 0 | Sealing Washer 16x20 Cu | |
| 18 | 2576 4680 68 01 | Banjo Body | |
| 19 | 1653 090180 1 | Banjo M18X1.5 | |
| 20 | 1622 071028 2 | Sealing Washer 18 x 22 | |
| 21 | 1642 080150 9 | Coupling Body L15 | |
| 22 | 2574 4680 01 04 | 3/8In Hp Hose Assy. With Wire Guard | |
| 25 | 2643 4680 01 24 | Assy Tube (Reservoir To Pump) | |
| 26 | 2643 4680 01 25 | Asst Tube (Reservoir To Pstrg GB) |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
