Каталог запасных частей к технике: Tata LP/LPT 613 LHD. OIL PUMP
1
2
3
4
4
5
6
7
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 8854 1808 25 25 | 8854 1808 25 25 | Gear Kit Oil Pump (50mm lg) consists of : | |
| 1 | 2525 1810 01 49 | Assy. Oil Pump with Strainer | |
| 2 | 2525 1810 37 04 | Oil Pump Housing | |
| 3 | 2525 1810 79 02 | Drive Shaft | |
| 4 | 2525 1810 54 05 | Gear, Drive Shaft | |
| 4 | Gear, Drive Shaft | Gear, Drive Shaft | |
| 5 | 1365 050505 5 | Woodruff Key 3x6.5 | |
| 6 | 312 181 03 08 | Drive, Gear | |
| 7 | Driven Gear, Oil Pump | Driven Gear, Oil Pump | |
| 7 | 2525 1810 54 06 | Driven Gear, Oil Pump | |
| 8 | 2525 1810 79 01 | Shaft For Drive Gear | |
| 9 | 352 181 12 20 | Cover, Oil Pump | |
| 10 | 352 184 03 29 | Valve Housing | |
| 11 | 326 993 04 01 | Spring, Pressure Relief Valve | |
| 12 | 321 181 00 42 | Plunger, Pressure Relief Valve | |
| 13 | 352 997 07 30 | Screw Plug | |
| 14 | 1132 419603 1 | Screw M 8x22 | |
| 15 | 1106 409601 1 | Bolt M 8x35 | |
| 16 | 1106 409603 8 | Bolt M 8x45 | |
| 17 | 1252 069802 5 | Spring Washer B 8 | |
| 18 | 2525 1815 01 15 | Assembly Strainer (Oil Pump) | |
| 19 | 312 186 00 80 | Gasket | |
| 20 | 1252 069802 5 | Spring Washer B 8 | |
| 21 | 1132 419602 3 | Screw M 8x20 | |
| 22 | 1134 240828 3 | Screw M 8x28 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
