Каталог запасных частей к технике: Tata LP/LPT 613 LHD. MOVING PARTS

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
2
3
4
5
6
7
8
9
9
10
11
12
13
14
14
14
15
15
16
16
16
17
17
17
17
17
17
18
18
18
18
18
18
19
19
19
19
20
20
20
20
21
21
21
21
21
22
22
23
23
24
24
25
25
26
26
26
27
27
27
28
28
28
29
29
29
30
30
31
33
35
37
37
37
37
37
Позиция на иллюстрации Заводской номер детали Название детали
Con. Rod Bush STD Con. Rod Bush STD Con. Rod Bush STD
Bearing Half (Upper & Lower) STD Bearing Half (Upper & Lower) STD Bearing Half (Upper & Lower) STD
Bearing Half (Upper & Lower) RS I Bearing Half (Upper & Lower) RS I Bearing Half (Upper & Lower) RS I
Bearing Half (Upper & Lower) RS II Bearing Half (Upper & Lower) RS II Bearing Half (Upper & Lower) RS II
Bearing Half (Upper & Lower) RS III Bearing Half (Upper & Lower) RS III Bearing Half (Upper & Lower) RS III
Bearing Half (Upper & Lower) RS IV Bearing Half (Upper & Lower) RS IV Bearing Half (Upper & Lower) RS IV
8854 0308 25 25 8854 0308 25 25 Kit, Crankshaft Sealing Ring with Locating Pins Consisting of :
2525 0313 82 01 2525 0313 82 01 Oil Slinger
1 2525 0310 79 34 Crank Shaft Std. (Integral Type)
2 2525 0311 01 33 Assy. Flywheel with Ring Gear
2 2525 0311 01 26 Assy. Flywheel with Ring Gear
3 352 032 11 05 Ring Gear
4 312 990 03 01 Bolt
5 312 994 02 32 Locking Plate
6 2534 0310 31 02 Ball Bearing
7 312 031 05 33 Locking Ring (In Crankshaft to Fix The Bearing)
8 352 052 00 03 Crank Shaft Gear
9 1365 051009 1 Woodruff Key 8x13
10 2525 0313 86 03 Spacer
11 352 030 31 03 Assy. Vibration Damper (Double Groove)
12 2523 0313 86 03 Thrust Spacer
13 2523 0313 32 02 Lock (V. Damper)
14 2525 0310 78 01 Sealing Ring Half
14 Sealing Ring Half Sealing Ring Half
15 Locating Pin Locating Pin
15 186 991 00 55 Pin
16 8854 0376 25 25 Thrust Washer Set (STD) Consisting of :
16 8854 0377 25 25 Thrust Washer Set (RS I) Consisting of :
16 8854 0378 25 25 Thrust Washer Set (RS II) Consisting of :
17 Bearing Upper Half RS II Bearing Upper Half RS II
17 Bearing Upper Half RS III Bearing Upper Half RS III
17 Bearing Upper Half RS IV Bearing Upper Half RS IV
17 Bearing Upper Half RS I Bearing Upper Half RS I
17 Bearing Upper Half STD Bearing Upper Half STD
18 Bearing Lower Half RS II Bearing Lower Half RS II
18 Bearing Lower Half RS I Bearing Lower Half RS I
18 Bearing Lower Half STD Bearing Lower Half STD
18 Bearing Lower Half RS IV Bearing Lower Half RS IV
18 Bearing Lower Half RS III Bearing Lower Half RS III
19 Thrust Washer Lower Half (116 mm Dia.) RS I Thrust Washer Lower Half (116 mm Dia.) RS I
19 Thrust Washer Lower Half (116 mm Dia.) RS II Thrust Washer Lower Half (116 mm Dia.) RS II
19 Thrust Washer Lower Half (116 mm Dia.) STD Thrust Washer Lower Half (116 mm Dia.) STD
20 Thrust Washer Upper Half (116 mm Dia.) RS I Thrust Washer Upper Half (116 mm Dia.) RS I
20 Thrust Washer Upper Half (116 mm Dia.) RS II Thrust Washer Upper Half (116 mm Dia.) RS II
20 Thrust Washer Upper Half (116 mm Dia.) STD Thrust Washer Upper Half (116 mm Dia.) STD
21 8854 0370 25 25 Main Bearing Set (STD) Consisting of :
21 8854 0372 25 25 Main Bearing Set (RS I) Consisting of :
21 8854 0373 25 25 Main Bearing Set (RS II) Consisting of :
21 8854 0374 25 25 Main Bearing Set (RS III) Consisting of :
21 8854 0375 25 25 Main Bearing Set (RS IV) Consisting of :
22 2525 0399 01 48 Bare Piston Set Std (BS II) Consisting of :
22 2525 0399 01 50 Set of Piston Rings Consisting of:
23 Piston Piston
23 Piston Piston
24 Piston Pin Piston Pin
24 Piston Pin Piston Pin
25 Circlip Circlip
25 Circlip Circlip
26 2525 0399 01 50 Set of Piston Rings Consisting of:
26 2525 0399 01 29 Set of Piston Ring Std Consisting of :
26 2525 0399 01 51 Set of Piston Rings Consisting of:
27 Double Trapez Ring (Gr I) Double Trapez Ring (Gr I)
27 Double Trapez Ring (Gr I) Double Trapez Ring (Gr I)
27 Double Trapez Ring (Gr I) Double Trapez Ring (Gr I)
28 Compression Ring (Gr II) Compression Ring (Gr II)
28 Compression Ring (Gr II) Compression Ring (Gr II)
28 Compression Ring (Gr II) Compression Ring (Gr II)
29 Assy. Oil Control Ring (Gr III) Assy. Oil Control Ring (Gr III)
29 Assy. Oil Control Ring (Gr III) Assy. Oil Control Ring (Gr III)
29 Assy. Oil Control Ring (Gr III) Assy. Oil Control Ring (Gr III)
30 2525 0315 01 07 Assy. Con. Rod Serrated (STD) with Bush
30 2525 0315 01 25 Assy. Con. Rod (STD) with Bush
31 8854 0368 25 25 Con. Rod Bush Set STD Consisting of :
33 1305 050714 3 Pin Cylindrical 6x14
35 2525 0315 32 05 Screw Con. Rod
37 8854 0362 25 25 Bearing Set for Con. Rod (Std) Consisting of :
37 8854 0364 25 25 Bearing Set for Con. Rod. RS I Consisting of :
37 8854 0365 25 25 Bearing Set for Con. Rod. RS II Consisting of :
37 8854 0366 25 25 Bearing Set for Con. Rod. RS III Consisting of :
37 8854 0367 25 25 Bearing Set for Con. Rod. RS IV Consists of :
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
