Каталог запасных частей к технике: Tata LP/LPT 613 LHD. INTERNAL AND EXTERNAL FITMENTS
21
22
23
23
26
27
28
29
30
31
32
32
33
34
35
35
37
37
38
38
40
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2641 8110 63 22 | 2641 8110 63 22 | Inner Beading | |
| 2641 8110 38 02 | 2641 8110 38 02 | Bracket Top RH.(R.VM.) | |
| 2641 8110 38 01 | 2641 8110 38 01 | Bracket Top LH. (R.V.M.) | |
| 2641 8110 38 04 | 2641 8110 38 04 | Bracket Bottom Rh.(R.V.M.) | |
| 2641 8110 38 03 | 2641 8110 38 03 | Bracket Bottom Lh.(R.V.M.) | |
| 2641 8110 63 30 | 2641 8110 63 30 | Rubber Pad(Bracket Top R.V.M) | |
| 2641 8110 63 31 | 2641 8110 63 31 | Rubber Pad(Bracket Bottom R.V.M) | |
| 2747 8150 69 01 | 2747 8150 69 01 | Grab Handle (Cowl) | |
| 2651 7250 63 16 | 2651 7250 63 16 | Grab Handle (On Door) | |
| 2641 8110 63 32 | 2641 8110 63 32 | Sleeve(For Frame R.V.M) | |
| 2641 8110 63 20 | 2641 8110 63 20 | Cap For Rear View Mirror | |
| 2641 8880 63 01 | 2641 8880 63 01 | Beading [Front Panel] | |
| 2641 8110 63 21 | 2641 8110 63 21 | Beading (Fire Wall) | |
| 2641 8110 63 23 | 2641 8110 63 23 | Bottom Beading (Centre Flap) | |
| 2651 8100 63 04 | 2651 8100 63 04 | Assy. Letter T | |
| 2651 8100 63 05 | 2651 8100 63 05 | Assy. Letter 'A' | |
| 2641 8190 01 14 | 2641 8190 01 14 | Assy. Cover Bazzle LH | |
| 2641 8190 01 15 | 2641 8190 01 15 | Assy. Cover Bazzle RH | |
| 2641 8110 01 08 | 2641 8110 01 08 | Lid Fuel Priming | |
| 2153 8106 01 01 | 2153 8106 01 01 | Assy. Step Additional | |
| 21 | 2641 8190 63 02 | Centre Grill (Front) | |
| 22 | 2641 8190 01 27 | ‘T’ Emblem Oval Stylised | |
| 23 | 2641 8190 01 01 | Assy. Bazzle RH | |
| 23 | 2641 8190 01 02 | Assy. Bazzle LH | |
| 26 | 2641 8190 01 11 | Assy. Cover Side LH | |
| 27 | 2641 8190 01 12 | Assy. Cover Side RH | |
| 28 | 2641 8190 01 13 | Assy. Cover Centre | |
| 29 | 2641 8190 63 06 | Grill LH | |
| 30 | 2641 8190 63 08 | Grill RH | |
| 31 | 2641 8190 63 09 | Grill Middle | |
| 32 | 2153 8110 69 01 | Grab Handle LH | |
| 32 | 2153 8110 69 02 | Grab Handle RH | |
| 33 | 2641 8110 01 44 | Assy. Cover LH (Centre Flap Hinge) | |
| 34 | 2641 8110 01 45 | Assy. Cover RH (Centre Flap Hinge) | |
| 35 | 2641 8110 01 11 | Assy. Sunvisor RH | |
| 35 | 2641 8110 01 12 | Assy. Sunvisor LH | |
| 37 | 2576 8110 01 53 | Rear View Mirror Outside LH | |
| 37 | 2576 8110 01 52 | Rear View Mirror Outside RH | |
| 38 | 2641 8110 01 38 | Assy. Frame Complete LH | |
| 38 | 2641 8110 01 39 | Assy. Frame Complete RH | |
| 40 | 2641 8190 01 22 | "Assy. Mascot ""613""" |
