Каталог запасных частей к технике: Tata LP/LPT 613 LHD. FUEL SYSTEM
1
3
3
3
4
4
4
7
9
10
10
11
11
12
12
20
21
22
22
23
25
26
27
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2647 4760 58 01 | 2647 4760 58 01 | Fuel Hose (Suction Side) | |
| 1622 051021 6 | 1622 051021 6 | Sealing Washer 14x18 AL | |
| 2643 4760 01 46 | 2643 4760 01 46 | Assy. Return Line (Socket To Hose) | |
| 2643 4760 01 13 | 2643 4760 01 13 | Assy. Suction Pipe | |
| 2643 4760 01 47 | 2643 4760 01 47 | Assy. Suction Line (Pump Hose To Intake) | |
| 2643 4760 01 45 | 2643 4760 01 45 | Assy. Suction Line (Socket To Pump) | |
| 1 | 2640 4710 01 11 | Assy. Fuel Tank Complete | |
| 3 | 1622 051057 7 | Sealing Washer 38x44 AL | |
| 4 | 1653 199904 9 | Pipe Union Bolt 10 | |
| 7 | 2651 5421 01 01 | Tank Unit | |
| 9 | 042 470 06 05J | Assy. Fuel Tank Cap | |
| 10 | 2640 4750 01 04 | Assy. Bracket (Fuel Tank Mtg) | |
| 11 | 2651 4750 01 02 | Assy. Strap | |
| 12 | 2651 4750 77 01 | Rubber Packing | |
| 20 | 2651 4710 01 59 | Assy. Fuel Line (Suction) | |
| 21 | 312 476 00 26 | Rubber Hose | |
| 22 | 1428 050020 9 | Hose Clamp 20 | |
| 23 | 2643 4760 01 48 | Assy. Suction Line (Fuel Tank to Water Separator) | |
| 25 | 2643 4760 01 49 | Assy. Suction Line (Water Separator to Socket) | |
| 26 | 2641 4710 01 09 | Water Separator | |
| 27 | 2641 4760 01 14 | Assy. Bracket (Water Separator) | |
| 29 | 2647 4760 58 02 | Fuel Hose (Engine Side) | |
| 30 | 2643 4760 01 43 | Assy. Return Line (Tank To Socket) |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
