Каталог запасных частей к технике: Tata LP/LPT 613 LHD. CAB MOUNTING (FRONT)

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано BAW DAF DongFeng FAW Foton HOWO Hyundai IVECO JAC Motors LGMG MAN Shaanxi SITRAK Studebaker Tata Volvo Автокомпонент Плюс БелАЗ Брянский Арсенал ГАЗ ЗИЛ КАЗ Камский автозавод КрАЗ Мадара МАЗ МЗКТ МоАЗ Нефтекамский автозавод Ставропольский Завод АвтоПрицепов ТАТРА Тонар УралАЗ ЧМЗАП

Модель Не выбрано LP/LPT 613 LHD (2006) LPT 1618 TC/52 (2009) LPT 613 Euro-III (2009) LPT 613 LHD EURO II (2009) LPT 613/34 WB Euro III (2009) SFC 407 LHD Euro II (2009)

Схема > Не выбрано ENGINE HALF BLOCK AND LONG BLOCK ENGINE OVERHAULING GASKET KIT CYLINDER BLOCK CYLINDER HEAD AND COVER MOVING PARTS ENGINE TIMING (CAMSHAFT & COMPONENTS) INJECTION TIMER FUEL INJECTION EQUIPMENT (EURO II) INJECTOR FUEL FEED AND LEAKAGE LINE (EURO II) FUEL FILTER AIR FILTER (EURO II) AIR COMPRESSOR 94 DIA AIR COMPRESSOR HEAD (REED VALVE TYPE) 94 DIA EXHAUST MANIFOLD AND TURBOCHARGER INTERCOOLER AND CONNECTIONS ALTERNATOR AND STARTER OIL PUMP ASSY. OIL FILTER OIL COOLER (PLATE T YPE) PISTON COOLING WATER PUMP ENGINE SUSPENSION CLUTCH 310 MM DIA GEAR BOX HOUSING GEAR SHAFT AND GEAR GEAR SHIFT LINKAGE CLUTCH AND BRAKE CONTROLS CLUTCH PIPE LINES ACCELERATOR CONTROL FRAME FRONT SPRING FRONT SHOCK ABSORBER FRONT ANTI-ROLL BAR (LP 613) REAR SPRING (For LPT 613) REAR SHOCK ABSORBER REAR ANTI - ROLL BAR FRONT AXLE REAR AXLE SPARE WHEEL CARRIER PROPELLER SHAFT FRONT WHEEL BRAKE (S-CAM) ABS REAR WHEEL BRAKE (S-CAM) AIR LINES AIR DRIER WITH TYRE INFLATOR DUAL BRAKE VALVE FRONT BRAKE CHAMBER FRONT AND REAR SLACK ADJUSTER REAR BRAKE ACTUATOR GRADUATED HAND BRAKE VALVE QUADRUPLE SYSTEM PROTECTION VALVE AIR CYLINDER WITH MAGNETIC VALVE STEERING LINKAGE POWER STEERING PIPELINES POWER STEERING COMPONENTS POWER STEERING PUMP POWER STEERING GEAR BOX (ZF) POWER STEERING HYDRAULIC TANK (ZF) FUEL SYSTEM EXHAUST SYSTEM RADIATOR & FITMENTS LIGHT AND SIGNAL INSTRUMENTS CAB/COWL WINDSHIELD GLASS DASHBOARD DOOR (LPT 613) DOOR LOCK WINDING REGULATOR AND GLASS INTERNAL AND EXTERNAL FITMENTS WIPER MOTOR AND LINKAGES CAB HEATING BUMPER CAB MOUNTING (FRONT) CAB MOUNTING (REAR) COWL MOUNTING MUDGUARD AND MUDFLAP SEAT AND SEAT BELTS

3

8

9

10

11

15

Позиция на иллюстрации	Заводской номер детали		Название детали
2641 8910 01 97	2641 8910 01 97		Assy. Mtg. Bracket Front Complete LH
2641 8910 01 45	2641 8910 01 45		Assy. Mtg. Bracket Front Complete RH
2641 8910 01 77	2641 8910 01 77		Assy. Mtg. Bracket Front Complete LH
2641 8910 01 75	2641 8910 01 75		Assy. Mtg. Bracket Front Complete RH
2641 8910 34 03	2641 8910 34 03		Serrated Bush RH (Cross Tube)
2641 8910 34 04	2641 8910 34 04		Spacer Bush
2641 8910 37 04	2641 8910 37 04		Adjuster RH (Torsion Bar)
2747 8910 82 42	2747 8910 82 42		Shim
2641 8910 80 04	2641 8910 80 04		Special Bolt (For Adjuster)
3	2673 8910 01 02		Cross Tube (Front Mounting)
8	2641 8910 01 54		Assy. Rubber Bush (Front Mtg.)
9	2641 8910 37 06		Mounting Bracket Bottom LH
10	2641 8910 37 05		Mounting Bracket Bottom RH
11	2641 8910 79 04		Torsion Bar
15	2641 8910 01 39		Assy. Stay Complete

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
