CARFRAME ASSEMBLY
AUXILIARY BEAM OF FRAME
FRAM FOREPART ACCESSORY
DRAW GEAR
SPECIAL AND VEHICLE TOOLS
CAB TILTING MECHANISM L.H. DRIVE VEHICLE
SPRING
CAB LOCKING DEVICE
LEFT/RIGHT FENDER BRACKET
FENDER LEFT BEHIND CAB
FENDER RIGHT BEHIND CAB
CAB HYDRAULIC TILTING EQUIPMENT
BUMPER AND FRONT BRACKET
LEFT FOOT PANEL BRACKET
RIGHT FOOT PANEL BRACKET
LEFT DOOR STEP
RIGHT DOOR STEP
REAR UNDERRUN PROTECTIVE DEVICES
CAB TYPE LETTERS
CAB DECORATE SCUTCHEON GLISTEN MARK
CAB TYPE LETTERS
WHEELING SYSTEM
SPARE WHEEL HOLDER
DC95319511830
DZ95319511830
1
2
3
4
5
6
7
8
9
10
11
Позиция на иллюстрации
Заводской номер детали
Название детали
DC95319511830
DC95319511830
Frame assembly
DZ95319511830
DZ95319511830
Frame assembly
1
DZ95319510879
Left carling assembly
2
DZ95319510882
Right carling assembly
3
DZ9114518985
Cross member assy
4
DZ9114518970
Cross member assy
5
DZ95259518920
Cross member assy
6
DZ9114510011
Connection base
7
DZ95319511883
Transom assembly
8
DZ95319511832
Reinforce plate of left
9
DZ95319511833
Reinforce plate of right
10
DZ9114860031
Transom
11
DZ95259517660
Rear cross member assy
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
