1
1
1
1
2
2
2
2
2
3
4
5
6
7
8
Позиция на иллюстрации
Заводской номер детали
Название детали
A
Conneting parts
Conneting parts
1
DZ97259366081
Nozzle
1
DZ97259366082
Nozzle
1
DZ97259366083
Nozzle
1
DZ97259366201
Nozzle
2
DZ97259366084
Nozzle
2
DZ97259366085
Nozzle
2
DZ97259366086
Nozzle
2
DZ97259366043
Nozzle
2
DZ97259366202
Nozzle
3
DZ97259366236
Nozzle
4
DZ97259366088
Tee joint
DZ97259366122
DZ97259366122
Tee joint
5
DZ97259360191
Tee joint
6
DZ97189366296
L-joint
7
DZ97259366279
T-joint
8
DZ97259366064
Tee joint
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
