Каталог запасных частей к технике: Shaanxi Shacman SX42584V324. DECORATIVE ASSEMBLY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
1
1
2
2
2
2
2
2
3
3
3
3
4
4
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
6
6
6
6
6
6
6
6
6
6
6
6
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
8
8
8
8
9
9
9
9
9
9
10
10
11
11
11
11
11
11
Позиция на иллюстрации Заводской номер детали Название детали
1 DZ14251979993 Right a-pillar outer decorative board
1 DZ14251970020 Right a-pillar outer decorative board
1 DZ14251979992 Right a-pillar outer decorative board
1 DZ14251972021 Right a-pillar outer decorative board
2 DZ14251970007 Front decorative board on the right side
2 DZ14251979995 Front decorative board on the right side
2 DZ14251971012 Decorative board on the right side/j
2 DZ14251979986 Decorative board on the right side/j
2 DZ14251972012 Decorative board on the right side/d
2 DZ14251979988 Decorative board on the right side/d
3 DZ14251970045 Sealing strip for side surrounding water tank
3 DZ14251970047 Sealing strip for side surrounding water tank
4 DZ14251970016 Decorative panels on the right side and rear
4 DZ14251979994 Decorative panels on the right side and rear
5 Q2140620 Винт
5 Q40106 Шайба 8х16х2-SТ-А3С
6 DZ14251970009 Plastic clip
7 Q2714219 Cross groove pan head self-tapping screw
7 Q40205 Шайба
8 DZ14251970019 Left a-pillar outer decorative board
8 DZ14251979997 Left a-pillar outer decorative board
8 DZ14251972019 Left a-pillar outer decorative board
8 DZ14251979991 Left a-pillar outer decorative board
9 DZ14251970006 Front decorative board on the left side
9 DZ14251979999 Front decorative board on the left side
9 DZ14251971011 Decorative panel left front
9 DZ14251979985 Decorative panel left front
9 DZ14251972011 Decorative panel left front
9 DZ14251979987 Decorative panel left front
10 DZ14251970015 Decorative panel left rear
10 DZ14251979998 Decorative panel left rear
11 Q2140616 Болт
11 Q40106 Шайба 8х16х2-SТ-А3С
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
