DZ15221744020
1
2
3
4
5
6
7
8
9
10
11
12
Позиция на иллюстрации
Заводской номер детали
Название детали
DZ15221744020
DZ15221744020
Water Container
1
DZ15221740040
Hose
2
DZ15221743020
Water Container
3
DZ15221740032
Water Container Right Bracket
4
Q2140445
Cross Recess Head Screw
5
Q40104
Flat washers
6
Q340B04
1 type hexagon nut
7
Q150B0820
Болт
8
Q40208
Шайба
9
Q40308
Шайба пружинная
10
DZ15221740031
Water Container Left Bracket
11
Q32006
Hex Nut
12
DZ15221740030
Water Container In-hose
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
