Каталог запасных частей к технике: Shaanxi Shacman SX3316DT426C. DOUBAL CIRCUIT BRAKE SYSTEM в…Ў
81.52101.6269
DZ9114360400
1
1
1
1
1
1
1
1
2
3
4
5
6
7
8
9
10
10
10
10
11
11
12
12
12
12
12
12
12
12
13
13
14
15
15
16
16
17
18
19
20
21
21
21
21
22
23
23
24
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 81.52101.6269 | 81.52101.6269 | Pressure limited | |
| DZ9114360400 | DZ9114360400 | Bracket | |
| 1 | DZ96189360000 | APU | |
| 1 | DZ96189369474 | APU | |
| 1 | DZ95189362020 | Air dryer | |
| 1 | DZ91189360016 | Air dryer | |
| 1 | DZ91189360049 | Air dryer | |
| 1 | DZ97189360018 | APU Breaket | |
| 1 | DZ96259360020 | Bracket | |
| 1 | DZ96189360003 | APU | |
| 2 | DZ97189360022 | Flexible tube | |
| 3 | DZ9100360320 | Fitting | |
| 4 | DZ95189362732 | Multi loop joint Breaket | |
| 5 | DZ95189360243 | Baroceptor Breaket | |
| 6 | DZ95259360105 | Relay valve | |
| 7 | DZ95259360106 | Relay valve | |
| 8 | AZ9014360047 | Relay valve | |
| 9 | 81.52340.0599 | Relay valve Breaket | |
| 10 | DZ95259362711 | Relay valve Breaket | |
| 10 | DZ95259362711 | Relay valve Breaket | |
| 11 | DZ95189360070 | Multi loop joint | |
| 11 | DZ95189362002 | Fitting assemble for assistant use | |
| 12 | DZ97259360107 | Air tank | |
| 12 | DZ97189360009 | Air tank | |
| 12 | DZ97259360008 | Air tank | |
| 12 | DZ93189360226 | Air tank | |
| 12 | DZ97259360210 | Air tank | |
| 12 | DZ97259360212 | Air tank | |
| 12 | DZ97259360007 | Air tank | |
| 12 | SZ905000009 | Air tank | |
| 13 | DZ97259366054 | Drainage valve | |
| 13 | AZ9100368155 | Кран водовыпуска | |
| 14 | DZ93189270001 | Pnumatic horn | |
| 15 | DZ9100360330 | With throttle trailer control valve | |
| 15 | DZ96259360079 | Trailer control valve Breaket | |
| 16 | 81.52340.0743 | Breaket | |
| 16 | DZ95189360400 | Breaket | |
| 17 | DZ9100360159 | Spiral tube assembly | |
| 18 | DZ9100360158 | Spiral tube assembly | |
| 19 | AZ9100369008 | Соеденительная коловка | |
| 20 | AZ9100369009 | Соеденительная коловка | |
| 21 | DZ9100360163 | Hose assembly | |
| 21 | DZ9100360165 | Hose | |
| 21 | DZ9100360173 | Hose | |
| 21 | DZ9100360175 | Hose | |
| 22 | SZ904000818 | Tube 12 right air chamber / hose | |
| 23 | DZ9100360163 | Hose assembly | |
| 23 | DZ9100360173 | Hose | |
| 24 | SZ904000819 | Tube 12 left air chamber / hose |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
