Каталог запасных частей к технике: LGMG MT86H. Steering assembly

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
2
3
4
4
5
5
5
5
5
5
5
6
6
6
6
6
6
7
8
9
10
10
11
12
13
14
15
15
16
17
17
18
19
19
20
20
21
22
23
24
25
25
26
27
28
29
30
31
32
32
33
34
35
36
37
37
38
38
38
39
39
40
41
42
43
44
45
46
47
48
48
48
49
49
50
51
51
52
53
53
54
54
55
56
57
57
58
58
58
59
60
60
61
62
63
64
65
66
67
68
68
69
69
70
70
71
71
72
72
73
74
74
75
76
77
78
79
79
80
80
81
81
82
82
83
84
85
85
86
87
88
89
90
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
106
106
106
107
107
107
108
109
110
Позиция на иллюстрации Заводской номер детали Название детали
1 27160110181 Clamp
2 4041010216 Cushion sleeve lgb123-0952
3 27160109111 Cushion
4 4011000084 Bolt gb5783-m10x30epzn-8.8
5 4015000162 Washer gb97.1-10epzn-300hv
6 4013000007 Nut gb6170-m10epzn-8
7 27150113421 Plate
8 27150111371 Oil suction rubber tube
9 4030100020 T-clamp45
10 4041010227 Hose assembly lgb165-003290
11 4041010375 Hose lgb165-010063
12 4120001797 Fitting
13 4041000084 Connecter lgb15501214
14 4030000285 O-ring gb3452.1-12.5x2.65g
15 4041001047 Connector lgb143-01406
16 4041010340 Hoselgb125-003243
17 4120002709 Priority valve vlc-60
18 4011000169 Bolt gb16674-m8x70epzn-8.8
19 4015000072 Washer gb97.1-8epzn-300hv
20 4013000033 Nut gb6170-m8epzn-8
21 4041001262 Joint lgb143-03019
22 4120002710 Joint 1cm-30-22wd
23 27160111461 Hose
24 27150108771 Plate
25 4011000489 Bolt gb5783-m10x50epzn-8.8
26 4011000049 Bolt gb5782-m10x55epzn-8.8
27 4120001247 Steering wheel-430
28 4120001388 Steering wheel pillar
29 4011000107 Bolt gb5783-m8x30epzn-8.8
30 4120001108 Steering rod
31 4120001109 Seat
32 4120000719 Redirector
33 4041001392 Cushion lgb123-0530
34 4041001269 Clamp lgb167-0530
35 4011000082 Bolt gb5783-m10x25epzn-8.8
36 27160104461 Plate
37 4013010119 Nut gb6185-m10epzn-8
38 27150110571 Plate
39 27150108321 Block
40 4011000136 Bolt gb16674-m10x85epzn-8.8
41 27150109931 Bracket
42 4011000094 Bolt gb5783-m16x30epzn-8.8
43 4015000181 Washer gb97.1-16epzn-300hv
44 27150111481 Plate
45 27150111491 Plate
46 27150111501 Plate
47 4120702759 Check valve
48 4041001218 Connecter lgb143-12213
49 4041010339 Hose lgb129-0062198
50 27150110411 Nipple
51 4030000280 O-ring gb3452.1-19.0x2.65g
52 27140105021 String casing
53 4015000168 Washer gb97.1-12epzn-300hv
54 4013000011 Nut gb6170-m12 epzn-8
55 27160108301 Brcaket
56 4041010211 Pipe clip lgb167-0846
57 4041001636 Cushion sleeve lgb123-0846
58 4011000197 Bolt gb5783-m12x30epzn-8.8
59 27150109041 Bracket
60 4011000184 Bolt gb5783-m10x40epzn-8.8
61 4041000822 Straight joint lgb155-01822
62 4190001347 Joint
63 4041000929 Hose
64 4041000700 Hose
65 27150111391 Clamp
66 4041000699 Pipe lgb127-006075
67 4120002012 Hydraulic cylinder hsgl-63x40x405-790
68 4015000288 Washer gb1230-12epzn-45
69 27150108681 Axis
70 4030000065 Grease cup jb7940.1-m10x1
71 27150108221 Sleeve
72 4030000107 Grease cup dust cap jxhf-00006
73 4041001004 Hose
74 27150106471 Plate
75 27150109101 Right steering tube
76 27150109081 Left steering tube
77 4120002025 Steering pump7077955974
78 27150111592 Steering suction nipple m27-32
79 27150109051 Clapboard joint
80 27150102951 Nut
81 4041010338 Hose lgb129-006163
82 4041010337 Hose lgb129-006159
83 4041000131 Joint lgb120-01412
84 4041000784 O-ring lgb168-10924
85 4041010336 Hose lgb166-010173
86 4041001417 Joint lgb143-12616
87 27150109061 Clapboard joint
88 27150103221 Nut
89 4190002536 T-connector
90 4041001006 Built-up joint lgb143-02616
91 27150109621 Rubber clip
92 4011000473 Bolt gb16674-m10x55epzn-8.8
93 4011000092 Bolt gb5783-m12x50epzn-8.8
94 27150109601 Plate
95 27150111191 Block
96 4021000253 Spherical plain bearing gb9163-ge30es
97 4041001040 Connecter
98 4030000090 O-ring 28.0x2.65g
99 4041000767 O-ring lgb168-11124
100 4041000133 Joint lgb120-01414
101 27150108851 Bracket
102 27150106671 Shaft
103 4011000564 Bolt gb5783-m16x45epzn-10.9
104 27150105311 Washer 16
105 4041000564 Joint lgb120-02620
106 4041000783 O-ring lgb168-11724
107 4041000132 Connecter lgb120-02220
108 27180102281 Protecting cover
109 27150108791 Nipple
110 4041000772 Plug
