Каталог запасных частей к технике: LGMG MT76A. Front suspension assembly
1
2
3
3
3
3
4
4
4
5
5
5
5
6
6
7
8
9
9
10
11
12
13
14
15
15
16
17
17
17
18
18
18
19
20
21
21
22
22
23
23
24
25
26
26
27
27
28
28
29
29
30
31
31
32
33
33
34
35
36
37
38
39
40
41
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4011010496 | Bolt gb5785-m18x1.5x90flznyc-12.9-480 | |
| 2 | 4014010080 | Screw gb70.1-m12x1.25x40epzn-8.8 | |
| 3 | 27120105412 | Washer 18 | |
| 4 | 4013010239 | Nut gb6185.2-m18x1.5flznyc-12-480 | |
| 5 | 4013010254 | Nut gb6170-m16flznyc-12-480 | |
| 6 | 27120100211 | Bolt protection tube | |
| 7 | 27120113681 | Cushion block | |
| 8 | 27120114992 | Wearing piece | |
| 9 | 27120100221 | Bolt | |
| 10 | 27120115681 | Front leaf sring front support saddle1 | |
| 11 | 4011010499 | Bolt gb5785-m18x1.5x80flznyc-12.9-480 | |
| 12 | 27120116331 | Bolt | |
| 13 | 4110001828 | Front the spring assembly | |
| 14 | 27120115601 | Spring pressing block | |
| 15 | 4015010257 | Nord-lock washer nl24sp | |
| 16 | 27120103611 | Self-locking nut with the shoulder | |
| 17 | 4013010120 | Nut gb6185-m12epzn-8 | |
| 18 | 4015000168 | Washer gb97.1-12epzn-300hv | |
| 19 | 4190000677 | Front suspennsion limiting block | |
| 20 | 4011000091 | Bolt gb5783-m12x40epzn-8.8 | |
| 21 | 4011000612 | Bolt gb5783-m16x55epzn-8.8 | |
| 22 | 4015000181 | Washer gb97.1-16epzn-300hv | |
| 23 | 4013010122 | Nut gb6185-m16epzn-88 | |
| 24 | 27120109871 | The limiting block bracket | |
| 25 | 27120113341 | Plate assembly | |
| 26 | 27120112021 | Washer | |
| 27 | 4190000636 | Block | |
| 28 | 4011000092 | Bolt gb5783-m12x50epzn-8.8 | |
| 29 | 27120113351 | Plate assembly | |
| 30 | 27120115691 | Front leaf sring rear support saddle | |
| 31 | 4011010497 | Bolt gb5785-m18x1.5x70flznyc-12.9-480 | |
| 32 | 4013010251 | Nut gb6185-m16flznyc-12-480 | |
| 33 | 4015010101 | Washer gb1230-16-45 | |
| 34 | 27120113491 | Second beam support | |
| 35 | 4011010585 | Bolt gb5786-m16x1.5x60flznyc-12.9-480 | |
| 36 | 4011010614 | Bolt gb5782-m16x80flznyc -12.9-480 | |
| 37 | 4013010114 | Nut gb6178-m36epzn-8 | |
| 38 | 4015000108 | Washer | |
| 39 | 27120113021 | Axis | |
| 40 | 4016000113 | Split pin gb91-6.3x63epzn-q235a | |
| 41 | 27120113501 | Second beam pole |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
