Каталог запасных частей к технике: LGMG MT76A. Cab
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
18
18
18
19
20
20
20
21
22
23
24
25
26
27
28
29
30
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 27130104141 | Left fender assembly | |
| 2 | 4011000207 | Bolt gb5783-m12x45epzn-8.8 | |
| 3 | 4013010120 | Nut gb6185-m12epzn-8 | |
| 4 | 4013000016 | Nut gb6170-m16epzn-8 | |
| 5 | 4015000305 | Washer gb96.1-16epzn-300hv | |
| 6 | 27130107671 | Trimmed gasket | |
| 7 | 27130107681 | Trimmed gasket | |
| 8 | 4013000118 | Nut gb6170-m5epzn-8 | |
| 9 | 27130114151 | Bumper assembly | |
| 10 | 27130102161 | Fog light protecting cap | |
| 11 | 4015000110 | Washer gb97.1-5epzn-300hv | |
| 12 | 4011000586 | Bolt gb16674-m5x25epzn-8.8 | |
| 13 | 4011000594 | Bolt gb5783-m16x60epzn-8.8 | |
| 14 | 4015000001 | Washer gb1230-16epzn-45 | |
| 15 | 4015000181 | Washer gb97.1-16epzn-300hv | |
| 16 | 27130104411 | Trim washer | |
| 17 | 4011000512 | Bolt gb5785-m16x1.5x50epzn-8.8 | |
| 18 | 4013010121 | Nut gb6185-m14epzn-8 | |
| 19 | 27130102494 | Front support base | |
| 20 | 4011010254 | Bolt gb5783-m14x55epzn-8.8a | |
| 21 | 27130103922 | Support bracket | |
| 22 | 27130103912 | Rubber mat | |
| 23 | 27130113171 | Adjustment shim 1 | |
| 24 | 27130113181 | Adjustment shim 2 | |
| 25 | 27130107003 | Intermediate stand | |
| 26 | 4011000338 | Bolt gb5783-m14x50epzn-8.8 | |
| 27 | 4015000177 | Washer gb97.1-14epzn-300hv | |
| 28 | 4015000188 | Washer gb96.1-14epzn-300hv | |
| 29 | 27360109211 | Support | |
| 30 | 27130104101 | Right fender assembly | |
| 31 | 4190003193 | Right fixed platform | |
| 32 | 4011000420 | Bolt gb5782-m14x90epzn-8.8 | |
| 33 | 4011000092 | Bolt gb5783-m12x50epzn-8.8 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
