Каталог запасных частей к технике: HOWO ZZ3327N3647C-N2WA. Main Shaft
2
4
5
7
10
13
16
19
22
22
22
26
26
26
26
26
28
28
28
28
28
31
31
31
31
31
41
43
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | AZ2203040101 | Main shaft assembly | |
| 2 | WG2203040221 | Main shaft | |
| 4 | Q5280310 | Pin | |
| 5 | WG2229040201 | Hex key | |
| 7 | WG2210040104 | 3rd gear | |
| 10 | WG2210040105 | 2nd gear | |
| 13 | WG2210040106 | 1st gear | |
| 16 | WG2210040103 | Spindle shift gears up | |
| 19 | WG2210040007 | R. Gear | |
| 22 | WG2210040210 | Main axle sleeve | |
| 26 | WG2229040003 | Clamp | |
| 28 | WG2210040012 | Spline block plate | |
| 31 | AZ2208040001 | Spline adjust plate | |
| 32 | WG2210040021 | Spline adjust plate | |
| 34 | WG2210040022 | Spline adjust plate | |
| 36 | WG2210040023 | Spline adjust plate | |
| 38 | WG2210040024 | Spline adjust plate | |
| 41 | WG2210040002 | Main axle block | |
| 43 | AZ2208040002 | Main shaft adjust shim | |
| 54 | WG2229040036 | Main shaft adjust shim | |
| 56 | WG2229040037 | Main shaft adjust shim | |
| 58 | WG2229040038 | Main shaft adjust shim | |
| 60 | WG2229040039 | Main shaft adjust shim |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
