Позиция на иллюстрации
Заводской номер детали
Название детали
1
WG1642777010
Rearview mirror assemby
2
WG1642777020
Rearview mirror assemby
3
Q214063OF31
Cross flute screw
4
Q2140625F31
Cross flute screw
5
Q40306F31
Spring washer
6
Q40106F31
Flat washer
7
Q40206F31
Washer
8
Q340B06F31
Hex nut
9
WG1642770099
Howo mirror assemby 50
10
AZ1642770097
Base plate
11
Q254062OF31
Cross flute screw
12
Q40306F31
Spring washer
13
Q218BO62OF31
Hex flute screw
14
WG1662770010
Down mirror assemby
15
WG1642770121
Down mirror bracket assemby
16
Q340B08F31
I type hex nut
17
Q40208F31
Washer
18
Q150B0825F31
Hex bolt
19
Q40308F31
Spring washer
