Каталог запасных частей к технике: HOWO Howo A7 8x4. Gears composite member

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5.1
5.2
5.3
5.4
6
7.1
7.2
7.3
7.4
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56.1
56.2
57
58
59
60
61
62
63
64
65
66
67
68
69
Позиция на иллюстрации Заводской номер детали Название детали
1 AZ2220100105 Transmission housing
2 WG9003326020 Roller bearing
3 Q5280630 Pin
4 Q5280430 Pin
5 AZ2203100002 Plant bracket assemby
5.1 WG9003821255 Hex screw
5.2 WG2225100002 Plant bracket assemby
5.3 WG2229100001 Torque sleeve
5.4 AZ2225100001 Output shaft
5.5 AZ9007970271 Glue
6 WG2229100005 Sun gear gasket
7 AZ2203100003 Sun roller and shealth assemby
7.1 WG2210100002 Spine sleeve
7.2 Q43875 Retainer
7.3 WG2210100003 Sleeve
7.4 WG2210100001 Sun gear
8 WG2212100001 Planet gear
9 WG2229100007 Block
10 WG9003321118 Roller
11 WG2210100004 Planet gear
12 WG2229100006 Shim
13 WG2229100008 Shim
14 WG9003991056 Retainer
15 WG9003326322 Roller bearing
16 WG9003991125 Retainer
17 WG9003321820 Roller bearing
18 WG2210100005 Annular gear
19 WG2210100006 Bracket
20 WG2229100012 Retainer
21 Q15081240 болт
22 Q40112 Шайба
23 WG2229100002 Torque sleeve
24 WG2203100005 Gear hub assemby
25 WG2229100032 Block sleeve
26 WG2210100009 Syn ring
27 WG2210100007 Syn tooth base
28 WG2229020001 Block
29 WG2229020002 Spring
30 WG2229020003 Spring cage
31 WG9003991130 Retainer
32 WG2210100008 Syn sleeve
33 WG2229100042 Shaft fork swing block
34 WG2214100001 Shaft fork
35 WG2203100006 Gear hub assemby
36 WG2203100007 Guide ring assemby
37 WG9003990024 Wave spring washer
38 WG2229100043 Shaft fork support pin
39 WG2229100048 Plate gasket
40 WG2229100041 End plate gasket
41 WG2229100047 Pto shaft cover
42 Q15081216 Hex bolt
43 Q40312 Пружинная шайба
44 WG9003326218 Roller bearing
45 22208100003 Adjust shim
45.1 WG2229100035 Adjust shim
45.2 WG2229100036 Adjust shim
45.3 WG2229100037 Adjust shim
46 WG2210100015 Range worm
47 WG9003072503 O-ring
48 WG9003071700 O-ring
49 WG2229100050 Piston
50 WG9003076900 O-ring
51 AZ9003870016 Hex nut
52 WG2229100049 Paper gasket
53 WG2222100009 Cyclinder
54 Q15OB1065 Hex bolt
55 Q40310 Пружинная шайба
56 AZ2203100008 End plate assemby
56.1 WG2222100001 End plate assemby
56.2 WG2203100009 Connected assemby
57 Q150B1055 болт
58 AZ9003070105 Oil seal
59 WG2210100018 Output flange
60 Q150B1020 болт
61 WG2229210019 Spring
62 WG2203100012 Pin
63 WG2229100056 Pin
64 WG2229100175 Subplate
65 Q15OB1025 Hex bolt
66 WG2229100052 Subplate
67 WG2229100054 Press block
68 WG2229100174 Subplate
69 WG2229100173 Locking plate
70 AZ9007990001 Glue
71 Q170B1055 Hex holed bolt
72 Q40310 Пружинная шайба
73 AZ9007970242 Glue
74 WG2229100072 Press block
75 WG2229100073 Bolt
76 Q150B0820 болт
77 AZ2229100075 Cover
78 Q40310 Пружинная шайба
79 AZ9007970271 Glue
80 WG2229100062 Paper gasket
81 WG2229100061 Hange plate
82 Q150B1050 Hex bolt
83 Q150B1060 Hex bolt
84 Q40310 Пружинная шайба
85 WG2229100011 Fasten nut
86 WG2229100071 Plug
87 WG2229100074 Locking plate
88 WG2214100002 Shaft fork
89 WG9003070800 O-ring
90 WG9003801187 Bolt
91 WG9003070800 O-ring
92 WG9003801058 Hex bolt
93 WG9003073150 O-ring
94 WG9003345138 Roller pin
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
