Каталог запасных частей к технике: Foton 4189SLFKA-AEZA01. 1SB2485350411 Instrument panel

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
10.1
10.2
10.3
10.4
10.5
10.6
Позиция на иллюстрации Заводской номер детали Название детали
23 Q2214816F31 Cross-recessed pan head self-tapping screw and big washer assembly
14 H4535010130A0 Instrument cover
15 Q2214216F31 Tapping screw
16 H4535010140A0 Panel assembly, driver side
17 H4535010150A0 Panel assembly, co-driver side
18 H4535010155A0 Apron panel, driver side
19 H4535010160A0 Apron panel, driver side
20 H4535010303A0 Apron panel, driver side
21 H4535010305A0 Apron panel, co-driver side
22 H4535010185A0 Maintenance lid assembly
13 H4535010322A0 Storage box
24 H4535010190A0 Retaining chute, maintenance lid
25 H4535010175A0 Retaining chute, apron panel
26 H4535010312A0 Storage box
27 1B24951200041 Гайка пластиковая
28 H4535010255A0 Subassembly
29 H4535010330A0 Footboard and bracket assembly, berth
30 Q2214222F31 Cross-recessed pan head self-tapping screw and big washer assembly
31 H4535010333A0 Bracket
10 H4535010250A0 Instrument panel module assembly
1 H4535030041A0 Attachment bracket, left end, instrument panel
2 H4535010120A0 Garnish, body, instrument panel
3 Q1460820 Болт с шестигранной головкой, пружинная шайба и плоская шайба
4 H4535010195A0 Angle plate assembly
5 H4535010196A0 Angle plate assembly
6 H4535010307A0 Mounting bracket, apron panel, co-driver side
7 Q32008 Гайка шестигранная с зубчатым буртиком
8 H4535030042A0 Attachment bracket, right end, instrument panel
9 H4535010320A0 Panel assembly, storage box
1SB2485350411 1SB2485350411 Instrument panel
10.1 H4535010010A0 Body assembly, instrument panel
10.2 H4535010040A0 Panel assembly, co-driver side
10.3 H4535010050A0 Base assembly, dashboard
10.4 H4535030060A0 Tubular beam set assembly
10.5 H4535010030A0 Panel assembly, driver side
10.6 H4535010060A0 Control panel assembly
11 Q1860616F31 Hexagon flange bolt-oversize series
12 H4535010310A0 Panel assembly, storage box
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
