Каталог запасных частей к технике: Foton 4189SLFKA-AEZA01. 1SB2485130402 Soundproof, insulating, damping, sealing devices

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1SB2485130402
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Позиция на иллюстрации Заводской номер детали Название детали
1SB2485130402 1SB2485130402 Soundproof, insulating, damping, sealing devices
1 Н4513020022А0 Heat insulator 12, high-top roof
2 Н4513020024А0 Heat insulator 14, high-top roof
3 Н4513020019А0 Heat insulator 9, high-top roof
4 Н4513020021АО Heat insulator 11, high-top roof
5 Н4513020023А0 Heat insulator 13, high-top roof
6 Н4513020020А0 Heat insulator 10, high-top roof
7 Н4513020017А0 Heat insulator 7, high-top roof
8 Н4513020018А0 Heat insulator 8, high-top roof
9 Н4513020016А0 Heat insulator 6, high-top roof
10 Н4513020014А0 Heat insulator 4, high-top roof
11 Н4513020011АО Heat insulator 1, high-top roof
12 Н451302001ЗАО Heat insulator 3, high-top roof
13 Н4513020012А0 Heat insulator 2, high-top roof
14 Н4513020015А0 Heat insulator 5, high-top roof
15 Н4513010011А0 Sound insulator 1, front wall
16 Н4513010012А0 Sound insulator 2, front wall
17 Н4513010013А0 Sound insulator 3, front wall
18 Н4513010014А0 Sound insulator 4, front wall
19 Н4513010015А0 Sound insulator 5, front wall
20 Н4513010017А0 Sound insulator 7, front wall
21 Н4513010016А0 Sound insulator 6, front wall
22 Н4513024102А0 Drum bag heat insulation pad
23 Н4513040016А0 Insulation mat button
24 Н4513010004А0 Sound insulator, floor
25 Н4513010003А0 Sound insulator, floor
26 Н4513040001АО Hole sticker 60, floor
27 Н4513040003А0 Hole sticker 25, floor
28 Н4513040002А0 Hole sticker 35, floor
29 Н4513040021АО Hole sticker 100, floor
30 Н4513040025А0 Block cover, panel, rear wall
31 Н4513040006А0 Block cover, panel, rear wall
32 Н4513040007АО Block cover, welded nut hole, rear wall
33 Н4513040008А0 Block cover, rear section, floor
34 H4513040009A0 Block cover, front panel
35 H4513040010A0 Double-layer rubber plug, rear wall
36 H4513040011A0 Block cover 1, side member, floor
37 H4513040012A0 Block cover 2, side member, floor
38 H4513040013A0 Block cover, side frame, floor
39 H4513014002A0 Acoustic board, wheel housing
40 H4513014001A0 Acoustic board, wheel housing
41 1K16951200804 Rubber plug
42 H4513024001A0 Heat insulator, wheel housing
43 H4513024003A0 Heat insulator, wheel housing
