1S42531730801
1
2
3
4
5
6
7
8
9
10
11
11
12
12
13
14
15
16
17
17
17
18
19
20
21
22
22
22
22
22
Позиция на иллюстрации
Заводской номер детали
Название детали
1S42531730801
1S42531730801
Gearbox operation mechanism
1
Q340B10
Гайка
2
Q40310
Шайба пружинная
3
1425317303003
Handle w/ valve assy
4
1424217300003
Upper dust cover
5
1424217300004
Upper pressure plate
6
Q150B0625
Болт
7
Q40106
Плоская шайба
8
Q40306
Шайба пружинная
9
1425317303002
Operation mechanism assy
10
1424217300005
Low pressure plate
11
1424217300008
Sealing gasket
12
1424217300007
Compound bush
13
1424217300006
Middle spacer bush
14
Q1440865
Hexagon head bolt and external sawtoothed locking-washer combination
15
Q40108
Плоская шайба
16
Q33008
Гайка шестигранная с буртиком
17
1B24981200026
Скоба
18
Q150B0820
Болт
19
Q2214216
Tapping screw
20
Q150B0830
Болт
21
Q340B08
Гайка
22
1417035600187
Хомут ленточный
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
