Каталог запасных частей к технике: Yuchai YC6MK375N-40. MY6MA-1307000/05 Water Pump Assembly

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано BAW Caterpillar Cummins DCEC DongFeng Doosan FAW Great Wall Hitachi HOWO HSW IVECO Komatsu LGMG Perkins Raywin SDEC Shaanxi Valmet Weichai XINCHAI YTO Yuchai ZF Алтайдизель Барнаултрансмаш ВТЗ ГАЗ ЗиД ЗМЗ Камский автозавод ММЗ СМД ТМЗ УМЗ ЧТЗ ЮМЗ ЯЗДА ЯМЗ

Модель Не выбрано YC4108C (D7400) (2010) YC4108ZG (D7802) (2010) YC4112ZQ (ZLQ) (2002) YC4A100-T301 (A515TB) (2021) YC4A115Z-T20 (2013) YC4B105Z-T20 (2016) YC4D (2005) YC4D120-20 (2008) YC4D120-20 (D1007) (2010) YC4D120-30 (D22J1) (2010) YC4D130-20 (D08FL) (2010) YC4D130-30 (D2102) (2010) YC4D140N-50 (2018) YC4D80-T10 (2009) YC4D80-T20 (2013) YC4E135-21 (E02D1) (2010) YC4E140-20 (E12N2) (2010) YC4E140-30 (E24FB) (2010) YC4E150-20 (E05D1) (2010) YC4E160-20 (E04F1) (2010) YC4E180-30 (E2100) (2010) YC4F100-20 (F31D8) (2010) YC4F115-20 (F30D8) (2010) YC4F115-30 (F50D1) (2010) YC4F90-23 (F60LA) (2010) YC4F90-30 (2008) YC4F90-30 (F51D1) (2010) YC4FA130-30 (FC7LA) (2010) YC4G180-20 (2014) YC4G180-20 (G0803) (2008) YC4G180-20 (G0803) (2010) YC4G180-30 (G2H0B) (2010) YC4G180N-30 (G2C0H-T1) (2010) YC4G180N-40 (2014) YC4G190N-50 (2014) YC4G200-30 (G2GQA) (2010) YC4G220-20 (G20JA) (2010) YC4ND27-90-30 (FD2D1) (2010) YC6108G (2008) YC6A240-20 (A3515) (2010) YC6A240-30 (A68SA) (2010) YC6A260-20 (A44AB) (2010) YC6A260-30 (A64YA) (2010) YC6B125-T10 (B7626) (2010) YC6B125-T11 (2016) YC6B125-T20 (2010) YC6B125-T21 (2016) YC6G220P-30 (G3FQA) (2010) YC6G230N-30 (G69MA) (2010) YC6G240-20 (G52MA) (2010) YC6G240-30 (2008) YC6G240-30 (G5BSB-T2) (2010) YC6G260N-20 (G64HA) (2010) YC6G260N-30 (G66YA-T12) (2010) YC6G260N-50 (2015) YC6G270-20 (G46MB) (2010) YC6G270-30 (G65QA) (2010) YC6G300-20 (G4704) (2010) YC6J125Z-T20 (2010) YC6J125Z-T21 (2015) YC6J125Z-T22 (2014) YC6J180-21 (J49D1) (2010) YC6J190-20 (J41D7) (2010) YC6J190-T301 (2021) YC6J210-20 (J42SA) (2010) YC6J210N-20 (J530C) (2010) YC6J210N-52 (2018) YC6J220-50 (2017) YC6J225N-52 (2014) YC6J230-20 (J4090) (2010) YC6J245-30 (J61LA) (2010) YC6J245-42 (J010N-T1) (2010) YC6J245-50 (2017) YC6K (2019) YC6K440N-50 (2013) YC6L250L-D30 (L7001) (2010) YC6L260-30 (2008) YC6L280-30 (L38MA) (2010) YC6L280N-52 (2014) YC6L310-30 (L360A) (2010) YC6L310-50 (2017) YC6L330-20 (L33YA) (2010) YC6L330-30 (L47SA) (2010) YC6L350-20 (L30JA) (2010) YC6M220G (M3020) (2010) YC6M280-20 (M36T1) (2010) YC6M290N-30 (M2CD1) (2010) YC6M290N-30 (M2CE1) (2010) YC6M320N-30 (M2BD1) (2010) YC6M340-20 (2009) YC6M340N-30 (M2AE1) (2010) YC6M360-30 (M6298) (2010) YC6M390-30 (M6000) (2010) YC6MK320N-50 (2013) YC6MK340N-50 (2013) YC6MK375N-40 (2014)

Схема > Не выбрано ME30N-1001000/01 Engine Suspension Assembly MY6MA-1002000/04 Cylinder Block Assembly MY6MA-1002200/05 Gear Housing Parts MY50A-1003000/03 Cylinder Head Assembly MY100-1004000/05 Piston And Connecting Rod Assembly MY3YA-1005000/03 Crankshaft Damper Assembly M5000-1006000/04 Camshaft Assembly MY9SA-1007000/02 Valve Train System Assembly MY9SA-1008100/04 and MYB00-1008500/05 Intake Manifold Assembly and Intake Connecting Pipe Assembly MY100-1008200/03 and MY100-1008400/01 Exhaust Pipe Parts and Exhaust Pipe Cover Parts MKPGA-1009000/08 Oil sump assembly MKPGA-1010000/05 Oil Filter Assembly K2000-1011000/02 Oil Pump Assembly KJ100-1012000/04 Oil Filter Assembly M6600-1013000/09 Oil Cooler Assembly M2AYA-1028000/04 Oil Dipstick Assembly MY3QP-1113000/01 Gas Supply Device Assembly MY2QP-1118000/06 Turbocharger Assembly MY4YA-1205000/01 Catalytic Converter Assembly MYB00-1107000/05 Gas Filter Assembly MYE00-1107000/03 Low Pressure Gas Filter Assembly MY100-1303000/03 Radiator Hose And Soft Hose Assembly 231-1305000/09 Water Drain Cock M60QB-1306000/08 Thermostat Assembly MY6MA-1307000/05 Water Pump Assembly MY2QP-1600000/01 Power Output Assembly MKCQP-3407000/02 Steering Pump Assembly M600A-3509000/02 Pneumatic Air Compressor MY100-3705000/08 Ignition System Assembly MY6MA-3701000/08 Alternator Assembly L47YA-3708000/01 Starter Assembly MYBQP-3823000/01 Controlling System Assembly MKB00-3904000/01 Nameplate

1

2

3

4

5

6

7

8

9

10

11

Позиция на иллюстрации	Заводской номер детали		Название детали
1	MS4YA-1307100B		Water pump
2	Q/YC147.1-72		Loop hoop
3	M7A00-1013084		Water pipe gasket
4	Q1841020TF2		Болт M10x20
5	M6600-1013061B		Соеденитель водяной трубки
6	M6600-1013002		Труба резиновая
7	Q618B04		Пробка NPT1/2
8	YC24-0510		Прямой штифт
9	Q1840860TF2		Болт M8x60
10	Q1841035		Болт M 10x35
11	Q1841040		Болт M10x40
