Каталог запасных частей к технике: Yuchai YC6MK340N-50. MN7A-1113000/01 Gas Supply Device Assembly
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Q150B0840 | Болт M8x40 | |
| 2 | Q40108 | Шайба 8 | |
| 3 | Q40308 | Шайба 8 | |
| 4 | MKC00-1113555 | Mixer gasket | |
| 5 | К1А00-1113540 | Mixer | |
| 6 | MKC00-1113554 | Mixer gasket | |
| 7 | MYB00-1113640 | Electronic throttle valve | |
| 8 | Q218B0650TF2 | Винт | |
| 9 | Q67689 | Hoop loop | |
| 10 | К1А00-1113642 | Throttle valve connecting pipe | |
| 11 | MY400-1113601 | Throttle valve intake connecting pipe | |
| 12 | Q1840816 | Болт M8x16 | |
| 13 | MN100-1113950 | Bracket | |
| 14 | Q1201085 | Stud | |
| 15 | Q40110 | Шайба 10 | |
| 16 | Q340B10 | Гайка М10 | |
| 17 | Q40310 | Шайба 10 | |
| 18 | MY100-1113301 | Gas cut-off valve, low pressure | |
| 19 | K4B00-1113C61A | Air outlet joint | |
| 20 | K1A00-1113302A | Hose | |
| 21 | K4B00-1113C61A | Air outlet joint | |
| 22 | MM100-1113302 | Hose | |
| 23 | Q1840840 | Болт M8x40 | |
| 24 | MKB00-1113907 | Anti-vibration pad | |
| 25 | МКВ00-1113911 | Cushion block | |
| 26 | МКВ00-1113906 | Spacer sleeve | |
| 27 | Q218B0660TF2 | Винт M6X60 | |
| 28 | MYF00-1113901A | Gas intake common rail pipe | |
| 29 | TN100-1113912 | Air intake joint | |
| 30 | YC208-B01800F | Уплотнительное кольцо 2,65x18 | |
| 31 | МКВ00-1113903 | Support sleeve | |
| 32 | LM200-1113905 | Plug | |
| 33 | MYF00-1113902A | Gas outlet common rail pipe | |
| 34 | Q18408120 | Bolt | |
| 35 | К1А00-Ш3940 | Metering valve | |
| 36 | TN100-1113553 | Mixer joint | |
| 37 | К1А00-1113909 | Thrust gum cover | |
| 38 | MYB00-1113905 | Plug | |
| 39 | MKB00-38231J0 | Nature gas temperature & pressure sensor | |
| 40 | Q1841225 | Болт | |
| 41 | MYB00-1113650A | Bracket | |
| 42 | K4L00-1113240-P64 | high presser | |
| 43 | J5700-1113282 | Hot water filling rubber pipe | |
| 44 | Q67616 | Хомут обруча | |
| 45 | Q67632 | Петля обруча 32 | |
| 46 | MYB00-111355C | Mixer connecting pipe |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
