Каталог запасных частей к технике: Yuchai YC6L310-50. LA20B-3701000/01 Generator Assembly
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
BAW
Caterpillar
Cummins
DCEC
DongFeng
Doosan
FAW
Great Wall
Hitachi
HOWO
HSW
IVECO
Komatsu
LGMG
Perkins
Raywin
SDEC
Shaanxi
Valmet
Weichai
XINCHAI
YTO
Yuchai
ZF
Алтайдизель
Барнаултрансмаш
ВТЗ
ГАЗ
ЗиД
ЗМЗ
Камский автозавод
ММЗ
СМД
ТМЗ
УМЗ
ЧТЗ
ЮМЗ
ЯЗДА
ЯМЗ
Модель
Не выбрано
YC4108C (D7400) (2010)
YC4108ZG (D7802) (2010)
YC4112ZQ (ZLQ) (2002)
YC4A100-T301 (A515TB) (2021)
YC4A115Z-T20 (2013)
YC4B105Z-T20 (2016)
YC4D (2005)
YC4D120-20 (2008)
YC4D120-20 (D1007) (2010)
YC4D120-30 (D22J1) (2010)
YC4D130-20 (D08FL) (2010)
YC4D130-30 (D2102) (2010)
YC4D140N-50 (2018)
YC4D80-T10 (2009)
YC4D80-T20 (2013)
YC4E135-21 (E02D1) (2010)
YC4E140-20 (E12N2) (2010)
YC4E140-30 (E24FB) (2010)
YC4E150-20 (E05D1) (2010)
YC4E160-20 (E04F1) (2010)
YC4E180-30 (E2100) (2010)
YC4F100-20 (F31D8) (2010)
YC4F115-20 (F30D8) (2010)
YC4F115-30 (F50D1) (2010)
YC4F90-23 (F60LA) (2010)
YC4F90-30 (2008)
YC4F90-30 (F51D1) (2010)
YC4FA130-30 (FC7LA) (2010)
YC4G180-20 (2014)
YC4G180-20 (G0803) (2008)
YC4G180-20 (G0803) (2010)
YC4G180-30 (G2H0B) (2010)
YC4G180N-30 (G2C0H-T1) (2010)
YC4G180N-40 (2014)
YC4G190N-50 (2014)
YC4G200-30 (G2GQA) (2010)
YC4G220-20 (G20JA) (2010)
YC4ND27-90-30 (FD2D1) (2010)
YC6108G (2008)
YC6A240-20 (A3515) (2010)
YC6A240-30 (A68SA) (2010)
YC6A260-20 (A44AB) (2010)
YC6A260-30 (A64YA) (2010)
YC6B125-T10 (B7626) (2010)
YC6B125-T11 (2016)
YC6B125-T20 (2010)
YC6B125-T21 (2016)
YC6G220P-30 (G3FQA) (2010)
YC6G230N-30 (G69MA) (2010)
YC6G240-20 (G52MA) (2010)
YC6G240-30 (2008)
YC6G240-30 (G5BSB-T2) (2010)
YC6G260N-20 (G64HA) (2010)
YC6G260N-30 (G66YA-T12) (2010)
YC6G260N-50 (2015)
YC6G270-20 (G46MB) (2010)
YC6G270-30 (G65QA) (2010)
YC6G300-20 (G4704) (2010)
YC6J125Z-T20 (2010)
YC6J125Z-T21 (2015)
YC6J125Z-T22 (2014)
YC6J180-21 (J49D1) (2010)
YC6J190-20 (J41D7) (2010)
YC6J190-T301 (2021)
YC6J210-20 (J42SA) (2010)
YC6J210N-20 (J530C) (2010)
YC6J210N-52 (2018)
YC6J220-50 (2017)
YC6J225N-52 (2014)
YC6J230-20 (J4090) (2010)
YC6J245-30 (J61LA) (2010)
YC6J245-42 (J010N-T1) (2010)
YC6J245-50 (2017)
YC6K (2019)
YC6K440N-50 (2013)
YC6L250L-D30 (L7001) (2010)
YC6L260-30 (2008)
YC6L280-30 (L38MA) (2010)
YC6L280N-52 (2014)
YC6L310-30 (L360A) (2010)
YC6L310-50 (2017)
YC6L330-20 (L33YA) (2010)
YC6L330-30 (L47SA) (2010)
YC6L350-20 (L30JA) (2010)
YC6M220G (M3020) (2010)
YC6M280-20 (M36T1) (2010)
YC6M290N-30 (M2CD1) (2010)
YC6M290N-30 (M2CE1) (2010)
YC6M320N-30 (M2BD1) (2010)
YC6M340-20 (2009)
YC6M340N-30 (M2AE1) (2010)
YC6M360-30 (M6298) (2010)
YC6M390-30 (M6000) (2010)
YC6MK320N-50 (2013)
YC6MK340N-50 (2013)
YC6MK375N-40 (2014)
Схема
>
Не выбрано
LND99-1001000/03 Engine Suspension Assembly
LA1KA-1002000/02 Cylinder Block Assembly
L64DD-1002200/05 Timing Gear Housing Parts
LC2MA-1003000/05 Cylinder Head and Cylinder Head Cover Assembly
L4700-1004000/01 Piston and Connecting Rod Assembly
LND99-1005000/02 Crankshaft Vibration Damper Assembly
L3000-1006000A/06 Camshaft Assembly
L3000-1007000/15 Valve Tappet Assembly
L38DA-1008100/09 Intake Pipe and andL520C-1008500/07 Intake Connecting Pipe Component
J61SA-1008200/08 Exhaust Pipe and J61SA-1008400/01 Exhaust Pipe Cover Component
LA2MB-1009000/05 Oil Sump Assembly
LA2MB-1010000/02 Oil Collector Assembly
L30YA-1011000/04 Oil Pump Assembly
L3000-1012000/05 Oil Strainer Assembly
L6AL1-1013000/02 Oil Cooler Assembly
L3000-1014000/10 Crankcase Ventilation Device Assembly
G5XE-1015000/05 Cold start aid system Assembly
LA2MB-1028000/04 Oil Dipstick Part
L6200-1104000/09 Fuel Supply Pipeline Assembly
J62MA-1105000/01 Fuel Filter Assembly
L6400-1111000/08 Fuel Injection Pump Assembly
L4700-1112000/09 Injector Assembly
L36QA-1118000/02 Turbocharger Assembly
CT-SR21RLBD5-0119/03 Exhaust aftertreatment assembly
231-1305000/10 Water Drain Cock Assembly
LA39A-1306000/02 Thermostat Assembly
L640G-1307000/05 Water Pump Assembly
L53YB-1600000/01 Power Output Assembly
LNDFA-3407000/01 Steering Pump Assembly
LA20B-3509000/03 Air Brake Air Compressor Assembly
LA20B-3701000/01 Generator Assembly
L47YA-3708000/01 Starter Assembly
LA20B-3823000/05 Control System Assembly
LA200-3904000/02 Nameplate
1
2
3
3
4
5
5
5
6
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19
20
21
22
23
24
25
Позиция на иллюстрации
Заводской номер детали
Название детали
1
MS40D-1002460
Poly V-belt idler subassembly
2
L62YB-3701045A
Alternator adjusting plate
3
Q150B10130TF2
Болт
4
Q150B1030TF2
Болт M10x30
5
Q40310
Шайба 10
6
Q40110
Шайба 10
7
Q150B1250TF2
Болт M12x50
8
YC24-B0816
Штифт
9
L62YB-3701100
Generator
10
J62YA-3701052B
Alternator adjusting plate
11
J63YA-3701002A
Alternator bracket
12
Q150B1245TF2
Bolt
13
Q40112
Шайба 12
14
Q40312
Шайба 12
15
Q340B12
Гайка М12
16
J02YS-1003122
Front engine eye
17
Q150B1050TF2
Болт M10x50
18
Q340B10
Гайка М10
19
J62YC-1002450A
Tensioning belt pulley
20
J62YC-3701002A
Alternator bracket
21
Q1840820TF2
Болт M8x20
22
L62YB-3701260A
Adjusting assembly
23
A30-1007092
Шайба
24
Q150B1025TF2
Болт M10x25
25
Q1841230TF2
Болт М12х30
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
