5. L640G-1307000/05 Water Pump Assembly

Каталог запасных частей к технике: Yuchai YC6L310-50. L640G-1307000/05 Water Pump Assembly

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано BAW Caterpillar Cummins DCEC DongFeng Doosan FAW Great Wall Hitachi HOWO HSW IVECO Komatsu LGMG Perkins Raywin SDEC Shaanxi Valmet Weichai XINCHAI YTO Yuchai ZF Алтайдизель Барнаултрансмаш ВТЗ ГАЗ ЗиД ЗМЗ Камский автозавод ММЗ СМД ТМЗ УМЗ ЧТЗ ЮМЗ ЯЗДА ЯМЗ

Модель Не выбрано YC4108C (D7400) (2010) YC4108ZG (D7802) (2010) YC4112ZQ (ZLQ) (2002) YC4A100-T301 (A515TB) (2021) YC4A115Z-T20 (2013) YC4B105Z-T20 (2016) YC4D (2005) YC4D120-20 (2008) YC4D120-20 (D1007) (2010) YC4D120-30 (D22J1) (2010) YC4D130-20 (D08FL) (2010) YC4D130-30 (D2102) (2010) YC4D140N-50 (2018) YC4D80-T10 (2009) YC4D80-T20 (2013) YC4E135-21 (E02D1) (2010) YC4E140-20 (E12N2) (2010) YC4E140-30 (E24FB) (2010) YC4E150-20 (E05D1) (2010) YC4E160-20 (E04F1) (2010) YC4E180-30 (E2100) (2010) YC4F100-20 (F31D8) (2010) YC4F115-20 (F30D8) (2010) YC4F115-30 (F50D1) (2010) YC4F90-23 (F60LA) (2010) YC4F90-30 (2008) YC4F90-30 (F51D1) (2010) YC4FA130-30 (FC7LA) (2010) YC4G180-20 (2014) YC4G180-20 (G0803) (2008) YC4G180-20 (G0803) (2010) YC4G180-30 (G2H0B) (2010) YC4G180N-30 (G2C0H-T1) (2010) YC4G180N-40 (2014) YC4G190N-50 (2014) YC4G200-30 (G2GQA) (2010) YC4G220-20 (G20JA) (2010) YC4ND27-90-30 (FD2D1) (2010) YC6108G (2008) YC6A240-20 (A3515) (2010) YC6A240-30 (A68SA) (2010) YC6A260-20 (A44AB) (2010) YC6A260-30 (A64YA) (2010) YC6B125-T10 (B7626) (2010) YC6B125-T11 (2016) YC6B125-T20 (2010) YC6B125-T21 (2016) YC6G220P-30 (G3FQA) (2010) YC6G230N-30 (G69MA) (2010) YC6G240-20 (G52MA) (2010) YC6G240-30 (2008) YC6G240-30 (G5BSB-T2) (2010) YC6G260N-20 (G64HA) (2010) YC6G260N-30 (G66YA-T12) (2010) YC6G260N-50 (2015) YC6G270-20 (G46MB) (2010) YC6G270-30 (G65QA) (2010) YC6G300-20 (G4704) (2010) YC6J125Z-T20 (2010) YC6J125Z-T21 (2015) YC6J125Z-T22 (2014) YC6J180-21 (J49D1) (2010) YC6J190-20 (J41D7) (2010) YC6J190-T301 (2021) YC6J210-20 (J42SA) (2010) YC6J210N-20 (J530C) (2010) YC6J210N-52 (2018) YC6J220-50 (2017) YC6J225N-52 (2014) YC6J230-20 (J4090) (2010) YC6J245-30 (J61LA) (2010) YC6J245-42 (J010N-T1) (2010) YC6J245-50 (2017) YC6K (2019) YC6K440N-50 (2013) YC6L250L-D30 (L7001) (2010) YC6L260-30 (2008) YC6L280-30 (L38MA) (2010) YC6L280N-52 (2014) YC6L310-30 (L360A) (2010) YC6L310-50 (2017) YC6L330-20 (L33YA) (2010) YC6L330-30 (L47SA) (2010) YC6L350-20 (L30JA) (2010) YC6M220G (M3020) (2010) YC6M280-20 (M36T1) (2010) YC6M290N-30 (M2CD1) (2010) YC6M290N-30 (M2CE1) (2010) YC6M320N-30 (M2BD1) (2010) YC6M340-20 (2009) YC6M340N-30 (M2AE1) (2010) YC6M360-30 (M6298) (2010) YC6M390-30 (M6000) (2010) YC6MK320N-50 (2013) YC6MK340N-50 (2013) YC6MK375N-40 (2014)

Схема > Не выбрано LND99-1001000/03 Engine Suspension Assembly LA1KA-1002000/02 Cylinder Block Assembly L64DD-1002200/05 Timing Gear Housing Parts LC2MA-1003000/05 Cylinder Head and Cylinder Head Cover Assembly L4700-1004000/01 Piston and Connecting Rod Assembly LND99-1005000/02 Crankshaft Vibration Damper Assembly L3000-1006000A/06 Camshaft Assembly L3000-1007000/15 Valve Tappet Assembly L38DA-1008100/09 Intake Pipe and andL520C-1008500/07 Intake Connecting Pipe Component J61SA-1008200/08 Exhaust Pipe and J61SA-1008400/01 Exhaust Pipe Cover Component LA2MB-1009000/05 Oil Sump Assembly LA2MB-1010000/02 Oil Collector Assembly L30YA-1011000/04 Oil Pump Assembly L3000-1012000/05 Oil Strainer Assembly L6AL1-1013000/02 Oil Cooler Assembly L3000-1014000/10 Crankcase Ventilation Device Assembly G5XE-1015000/05 Cold start aid system Assembly LA2MB-1028000/04 Oil Dipstick Part L6200-1104000/09 Fuel Supply Pipeline Assembly J62MA-1105000/01 Fuel Filter Assembly L6400-1111000/08 Fuel Injection Pump Assembly L4700-1112000/09 Injector Assembly L36QA-1118000/02 Turbocharger Assembly CT-SR21RLBD5-0119/03 Exhaust aftertreatment assembly 231-1305000/10 Water Drain Cock Assembly LA39A-1306000/02 Thermostat Assembly L640G-1307000/05 Water Pump Assembly L53YB-1600000/01 Power Output Assembly LNDFA-3407000/01 Steering Pump Assembly LA20B-3509000/03 Air Brake Air Compressor Assembly LA20B-3701000/01 Generator Assembly L47YA-3708000/01 Starter Assembly LA20B-3823000/05 Control System Assembly LA200-3904000/02 Nameplate

1

2

3

4

5

6

7

8

9

10

Позиция на иллюстрации	Заводской номер детали		Название детали
1	YC208-C03550S		Уплотнительное кольцо 3,55x35.5
2	L62YS-1307100A		Water pump
3	YC150-36E		Compound seal washer
4	Q1841085TF2		Болт M10X85
5	177-1306023C		Резьбовая пробка
6	YC80-10PK-2390BG		Poly V-belt
7	L360A-3800101		Разъем датчика температуры воды
8	YC150-14E		Mixted type sealing washer
9	Q618B03		Пробка NPT3/8
10	YC208-C04000S		Кольцевая прокладка 3.55X40

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
