CT-SR21RLBD5-0119/03 Exhaust aftertreatment assembly
Каталог запасных частей к технике: Yuchai YC6L310-50. CT-SR21RLBD5-0119/03 Exhaust aftertreatment assembly
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
BAW
Caterpillar
Cummins
DCEC
DongFeng
Doosan
FAW
Great Wall
Hitachi
HOWO
HSW
IVECO
Komatsu
LGMG
Perkins
Raywin
SDEC
Shaanxi
Valmet
Weichai
XINCHAI
YTO
Yuchai
ZF
Алтайдизель
Барнаултрансмаш
ВТЗ
ГАЗ
ЗиД
ЗМЗ
Камский автозавод
ММЗ
СМД
ТМЗ
УМЗ
ЧТЗ
ЮМЗ
ЯЗДА
ЯМЗ
Модель
Не выбрано
YC4108C (D7400) (2010)
YC4108ZG (D7802) (2010)
YC4112ZQ (ZLQ) (2002)
YC4A100-T301 (A515TB) (2021)
YC4A115Z-T20 (2013)
YC4B105Z-T20 (2016)
YC4D (2005)
YC4D120-20 (2008)
YC4D120-20 (D1007) (2010)
YC4D120-30 (D22J1) (2010)
YC4D130-20 (D08FL) (2010)
YC4D130-30 (D2102) (2010)
YC4D140N-50 (2018)
YC4D80-T10 (2009)
YC4D80-T20 (2013)
YC4E135-21 (E02D1) (2010)
YC4E140-20 (E12N2) (2010)
YC4E140-30 (E24FB) (2010)
YC4E150-20 (E05D1) (2010)
YC4E160-20 (E04F1) (2010)
YC4E180-30 (E2100) (2010)
YC4F100-20 (F31D8) (2010)
YC4F115-20 (F30D8) (2010)
YC4F115-30 (F50D1) (2010)
YC4F90-23 (F60LA) (2010)
YC4F90-30 (2008)
YC4F90-30 (F51D1) (2010)
YC4FA130-30 (FC7LA) (2010)
YC4G180-20 (2014)
YC4G180-20 (G0803) (2008)
YC4G180-20 (G0803) (2010)
YC4G180-30 (G2H0B) (2010)
YC4G180N-30 (G2C0H-T1) (2010)
YC4G180N-40 (2014)
YC4G190N-50 (2014)
YC4G200-30 (G2GQA) (2010)
YC4G220-20 (G20JA) (2010)
YC4ND27-90-30 (FD2D1) (2010)
YC6108G (2008)
YC6A240-20 (A3515) (2010)
YC6A240-30 (A68SA) (2010)
YC6A260-20 (A44AB) (2010)
YC6A260-30 (A64YA) (2010)
YC6B125-T10 (B7626) (2010)
YC6B125-T11 (2016)
YC6B125-T20 (2010)
YC6B125-T21 (2016)
YC6G220P-30 (G3FQA) (2010)
YC6G230N-30 (G69MA) (2010)
YC6G240-20 (G52MA) (2010)
YC6G240-30 (2008)
YC6G240-30 (G5BSB-T2) (2010)
YC6G260N-20 (G64HA) (2010)
YC6G260N-30 (G66YA-T12) (2010)
YC6G260N-50 (2015)
YC6G270-20 (G46MB) (2010)
YC6G270-30 (G65QA) (2010)
YC6G300-20 (G4704) (2010)
YC6J125Z-T20 (2010)
YC6J125Z-T21 (2015)
YC6J125Z-T22 (2014)
YC6J180-21 (J49D1) (2010)
YC6J190-20 (J41D7) (2010)
YC6J190-T301 (2021)
YC6J210-20 (J42SA) (2010)
YC6J210N-20 (J530C) (2010)
YC6J210N-52 (2018)
YC6J220-50 (2017)
YC6J225N-52 (2014)
YC6J230-20 (J4090) (2010)
YC6J245-30 (J61LA) (2010)
YC6J245-42 (J010N-T1) (2010)
YC6J245-50 (2017)
YC6K (2019)
YC6K440N-50 (2013)
YC6L250L-D30 (L7001) (2010)
YC6L260-30 (2008)
YC6L280-30 (L38MA) (2010)
YC6L280N-52 (2014)
YC6L310-30 (L360A) (2010)
YC6L310-50 (2017)
YC6L330-20 (L33YA) (2010)
YC6L330-30 (L47SA) (2010)
YC6L350-20 (L30JA) (2010)
YC6M220G (M3020) (2010)
YC6M280-20 (M36T1) (2010)
YC6M290N-30 (M2CD1) (2010)
YC6M290N-30 (M2CE1) (2010)
YC6M320N-30 (M2BD1) (2010)
YC6M340-20 (2009)
YC6M340N-30 (M2AE1) (2010)
YC6M360-30 (M6298) (2010)
YC6M390-30 (M6000) (2010)
YC6MK320N-50 (2013)
YC6MK340N-50 (2013)
YC6MK375N-40 (2014)
Схема
>
Не выбрано
LND99-1001000/03 Engine Suspension Assembly
LA1KA-1002000/02 Cylinder Block Assembly
L64DD-1002200/05 Timing Gear Housing Parts
LC2MA-1003000/05 Cylinder Head and Cylinder Head Cover Assembly
L4700-1004000/01 Piston and Connecting Rod Assembly
LND99-1005000/02 Crankshaft Vibration Damper Assembly
L3000-1006000A/06 Camshaft Assembly
L3000-1007000/15 Valve Tappet Assembly
L38DA-1008100/09 Intake Pipe and andL520C-1008500/07 Intake Connecting Pipe Component
J61SA-1008200/08 Exhaust Pipe and J61SA-1008400/01 Exhaust Pipe Cover Component
LA2MB-1009000/05 Oil Sump Assembly
LA2MB-1010000/02 Oil Collector Assembly
L30YA-1011000/04 Oil Pump Assembly
L3000-1012000/05 Oil Strainer Assembly
L6AL1-1013000/02 Oil Cooler Assembly
L3000-1014000/10 Crankcase Ventilation Device Assembly
G5XE-1015000/05 Cold start aid system Assembly
LA2MB-1028000/04 Oil Dipstick Part
L6200-1104000/09 Fuel Supply Pipeline Assembly
J62MA-1105000/01 Fuel Filter Assembly
L6400-1111000/08 Fuel Injection Pump Assembly
L4700-1112000/09 Injector Assembly
L36QA-1118000/02 Turbocharger Assembly
CT-SR21RLBD5-0119/03 Exhaust aftertreatment assembly
231-1305000/10 Water Drain Cock Assembly
LA39A-1306000/02 Thermostat Assembly
L640G-1307000/05 Water Pump Assembly
L53YB-1600000/01 Power Output Assembly
LNDFA-3407000/01 Steering Pump Assembly
LA20B-3509000/03 Air Brake Air Compressor Assembly
LA20B-3701000/01 Generator Assembly
L47YA-3708000/01 Starter Assembly
LA20B-3823000/05 Control System Assembly
LA200-3904000/02 Nameplate
L6200-1205315
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Позиция на иллюстрации
Заводской номер детали
Название детали
L6200-1205315
L6200-1205315
Metering injection pump name plate I
1
MX100-1205740
Antifreezing fluid solenoid valve
2
L4400-1205340A
Measuring injection pump
3
L4400-1205470C
Compressed air filter
4
L4400-1205472
Withhold nut
5
Q340B04
Nut
6
Q40304
Шайба 4
7
Q40104
Шайба 4
8
L4400-1205473B
Compressed air filter bracket
9
Q150B0445TF2
Болт M4X45
10
L4400-1205503B
Nozzle holder
11
L4400-1205582A
Nozzle gasket
12
LA600-1205580SF8
Nozzle
13
L6400-1205150A
Nitrogen oxide sensor
14
LNA00-1205170A
After catalysis temperature sensor
15
LA200-1205140-L
Catalytic Muffler
16
K1000-1205101
Catalytic muffler gasket
17
L4400-1205111
Прокладка датчика температуры
18
LNC00-1205160
first catalysis temperature sensor
19
L4400-1205240D
Add blue cans
20
LA100-1205145
NOx sensor seat
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
