J8004-1005000/01 Crankshaft Vibration Damper Assembly
Каталог запасных частей к технике: Yuchai YC6J125Z-T21. J8004-1005000/01 Crankshaft Vibration Damper Assembly
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
BAW
Caterpillar
Cummins
DCEC
DongFeng
Doosan
FAW
Great Wall
Hitachi
HOWO
HSW
IVECO
Komatsu
LGMG
Perkins
Raywin
SDEC
Shaanxi
Valmet
Weichai
XINCHAI
YTO
Yuchai
ZF
Алтайдизель
Барнаултрансмаш
ВТЗ
ГАЗ
ЗиД
ЗМЗ
Камский автозавод
ММЗ
СМД
ТМЗ
УМЗ
ЧТЗ
ЮМЗ
ЯЗДА
ЯМЗ
Модель
Не выбрано
YC4108C (D7400) (2010)
YC4108ZG (D7802) (2010)
YC4112ZQ (ZLQ) (2002)
YC4A100-T301 (A515TB) (2021)
YC4A115Z-T20 (2013)
YC4B105Z-T20 (2016)
YC4D (2005)
YC4D120-20 (2008)
YC4D120-20 (D1007) (2010)
YC4D120-30 (D22J1) (2010)
YC4D130-20 (D08FL) (2010)
YC4D130-30 (D2102) (2010)
YC4D140N-50 (2018)
YC4D80-T10 (2009)
YC4D80-T20 (2013)
YC4E135-21 (E02D1) (2010)
YC4E140-20 (E12N2) (2010)
YC4E140-30 (E24FB) (2010)
YC4E150-20 (E05D1) (2010)
YC4E160-20 (E04F1) (2010)
YC4E180-30 (E2100) (2010)
YC4F100-20 (F31D8) (2010)
YC4F115-20 (F30D8) (2010)
YC4F115-30 (F50D1) (2010)
YC4F90-23 (F60LA) (2010)
YC4F90-30 (2008)
YC4F90-30 (F51D1) (2010)
YC4FA130-30 (FC7LA) (2010)
YC4G180-20 (2014)
YC4G180-20 (G0803) (2008)
YC4G180-20 (G0803) (2010)
YC4G180-30 (G2H0B) (2010)
YC4G180N-30 (G2C0H-T1) (2010)
YC4G180N-40 (2014)
YC4G190N-50 (2014)
YC4G200-30 (G2GQA) (2010)
YC4G220-20 (G20JA) (2010)
YC4ND27-90-30 (FD2D1) (2010)
YC6108G (2008)
YC6A240-20 (A3515) (2010)
YC6A240-30 (A68SA) (2010)
YC6A260-20 (A44AB) (2010)
YC6A260-30 (A64YA) (2010)
YC6B125-T10 (B7626) (2010)
YC6B125-T11 (2016)
YC6B125-T20 (2010)
YC6B125-T21 (2016)
YC6G220P-30 (G3FQA) (2010)
YC6G230N-30 (G69MA) (2010)
YC6G240-20 (G52MA) (2010)
YC6G240-30 (2008)
YC6G240-30 (G5BSB-T2) (2010)
YC6G260N-20 (G64HA) (2010)
YC6G260N-30 (G66YA-T12) (2010)
YC6G260N-50 (2015)
YC6G270-20 (G46MB) (2010)
YC6G270-30 (G65QA) (2010)
YC6G300-20 (G4704) (2010)
YC6J125Z-T20 (2010)
YC6J125Z-T21 (2015)
YC6J125Z-T22 (2014)
YC6J180-21 (J49D1) (2010)
YC6J190-20 (J41D7) (2010)
YC6J190-T301 (2021)
YC6J210-20 (J42SA) (2010)
YC6J210N-20 (J530C) (2010)
YC6J210N-52 (2018)
YC6J220-50 (2017)
YC6J225N-52 (2014)
YC6J230-20 (J4090) (2010)
YC6J245-30 (J61LA) (2010)
YC6J245-42 (J010N-T1) (2010)
YC6J245-50 (2017)
YC6K (2019)
YC6K440N-50 (2013)
YC6L250L-D30 (L7001) (2010)
YC6L260-30 (2008)
YC6L280-30 (L38MA) (2010)
YC6L280N-52 (2014)
YC6L310-30 (L360A) (2010)
YC6L310-50 (2017)
YC6L330-20 (L33YA) (2010)
YC6L330-30 (L47SA) (2010)
YC6L350-20 (L30JA) (2010)
YC6M220G (M3020) (2010)
YC6M280-20 (M36T1) (2010)
YC6M290N-30 (M2CD1) (2010)
YC6M290N-30 (M2CE1) (2010)
YC6M320N-30 (M2BD1) (2010)
YC6M340-20 (2009)
YC6M340N-30 (M2AE1) (2010)
YC6M360-30 (M6298) (2010)
YC6M390-30 (M6000) (2010)
YC6MK320N-50 (2013)
YC6MK340N-50 (2013)
YC6MK375N-40 (2014)
Схема
>
Не выбрано
J8AG1-1001000/02 Engine Suspension Assembly
J8AG1-1002000/01 Cylinder Block Assembly
J8000-1002030/10 Gear Housing Parts
J80G1-1003000/02 Cylinder Head and Cylinder Head Cover Assembly
J3200-1004000/01 Piston and Connecting Rod Assembly
J8004-1005000/01 Crankshaft Vibration Damper Assembly
630-1006000A/02 Camshaft Assembly
J3200-1007000/07 Valve Tappet Assembly
J8AG1-1008100/02 Intake Pipe parts
J80GM-1008200/01 Exhaust Pipe Parts
641-1009000/04 Oil Sump Assembly
1640H-1010000/05 Oil Collector Assembly
B3000-1011000/05 Oil Pump Assembly
J8001-1012000/03 Oil Filter Assembly
J8004-1013000/08 Oil Cooler Assembly
311-1014000/05 Breather Part
630-1028000/01 Oil Dipstick Assembly
J8AG1-1104000/03 Supply System Pipeline Assembly
J8006-1105000/01 Fuel Filter Assembly
J8000-1109000/09 Air Cleaner Assembly
J8004-1111000/01 Injection Pump Assembly
J3400-1112000/04 Injector Assembly
J8004-1115000/01 Fuel Cut-off Institution Assembly
J7M00-1118000/02 Turbocharger Assembly
B7B06-1130000/02 Fuel Injection Pump Accessory Assembly
J80GM-1201000/01 Muffler Assembly
J8004-1303000/09 Water Pipe and Hose Assembly of Radiator
631-1305000/06 Water Drain Cock Assembly
J8000-1306000/11 Thermostat Assembly
J80G1-1307000/03 Water Pump Assembly
396-1308000/02 Fan Assembly
J8AG1-1600000/01 Power Output Assembly
J8000—3509000/12 Pneumatic Air Compressor Assembly
J8004-3701000/06 Alternator Assembly
B7641-3708000/03 Starter Assembly
B7648-3800000/01 Instrument and Sensors Assembly
J8A00-3904000/01 Nameplate
6105Q-1005054C*-L
6105Q-1005054C*-H
630-1005020F
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Позиция на иллюстрации
Заводской номер детали
Название детали
6105Q-1005054C*-L
6105Q-1005054C*-L
Crankshaft bearing shell subassembly
6105Q-1005054C*-H
6105Q-1005054C*-H
Crankshaft bearing shell subassembly
630-1005020F
630-1005020F
Crankshaft
1
Q150B1060TF2
Болт M10x60
2
Q40310
Шайба 10
3
Q40110
Шайба 10
4
640-1005031B
Crankshaft-cooler belt pulley
5
637-1005052
Fasten bolt,crankshaft pulley
6
J8000-1005030A
Belt pulley vibration damper subassembly
7
6105Q-1005021
Распределительная шестерня коленчатого вала
8
Q5511270
Шпонка
9
630-1005020E
Коленчатый вал
10
6105Q-1005056A
Верхний вкладыш
11
6105Q-1005058A
Упорный вкладыш коленчатого вала
12
6105Q-1005057C
Нижний вкладыш
13
6105Q-1005054A
Верхний вкладыш
14
6105Q-1005055C
Нижний вкладыш
15
YC24-B1226
Цилиндрический палец 12х26
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
