YC6J125Z-T20
J7M00-1118000/01 Turbocharger Assembly
Каталог запасных частей к технике: Yuchai YC6J125Z-T20. J7M00-1118000/01 Turbocharger Assembly
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
BAW
Caterpillar
Cummins
DCEC
DongFeng
Doosan
FAW
Great Wall
Hitachi
HOWO
HSW
IVECO
Komatsu
LGMG
Perkins
Raywin
SDEC
Shaanxi
Valmet
Weichai
XINCHAI
YTO
Yuchai
ZF
Алтайдизель
Барнаултрансмаш
ВТЗ
ГАЗ
ЗиД
ЗМЗ
Камский автозавод
ММЗ
СМД
ТМЗ
УМЗ
ЧТЗ
ЮМЗ
ЯЗДА
ЯМЗ
Модель
Не выбрано
YC4108C (D7400) (2010)
YC4108ZG (D7802) (2010)
YC4112ZQ (ZLQ) (2002)
YC4A100-T301 (A515TB) (2021)
YC4A115Z-T20 (2013)
YC4B105Z-T20 (2016)
YC4D (2005)
YC4D120-20 (2008)
YC4D120-20 (D1007) (2010)
YC4D120-30 (D22J1) (2010)
YC4D130-20 (D08FL) (2010)
YC4D130-30 (D2102) (2010)
YC4D140N-50 (2018)
YC4D80-T10 (2009)
YC4D80-T20 (2013)
YC4E135-21 (E02D1) (2010)
YC4E140-20 (E12N2) (2010)
YC4E140-30 (E24FB) (2010)
YC4E150-20 (E05D1) (2010)
YC4E160-20 (E04F1) (2010)
YC4E180-30 (E2100) (2010)
YC4F100-20 (F31D8) (2010)
YC4F115-20 (F30D8) (2010)
YC4F115-30 (F50D1) (2010)
YC4F90-23 (F60LA) (2010)
YC4F90-30 (2008)
YC4F90-30 (F51D1) (2010)
YC4FA130-30 (FC7LA) (2010)
YC4G180-20 (2014)
YC4G180-20 (G0803) (2008)
YC4G180-20 (G0803) (2010)
YC4G180-30 (G2H0B) (2010)
YC4G180N-30 (G2C0H-T1) (2010)
YC4G180N-40 (2014)
YC4G190N-50 (2014)
YC4G200-30 (G2GQA) (2010)
YC4G220-20 (G20JA) (2010)
YC4ND27-90-30 (FD2D1) (2010)
YC6108G (2008)
YC6A240-20 (A3515) (2010)
YC6A240-30 (A68SA) (2010)
YC6A260-20 (A44AB) (2010)
YC6A260-30 (A64YA) (2010)
YC6B125-T10 (B7626) (2010)
YC6B125-T11 (2016)
YC6B125-T20 (2010)
YC6B125-T21 (2016)
YC6G220P-30 (G3FQA) (2010)
YC6G230N-30 (G69MA) (2010)
YC6G240-20 (G52MA) (2010)
YC6G240-30 (2008)
YC6G240-30 (G5BSB-T2) (2010)
YC6G260N-20 (G64HA) (2010)
YC6G260N-30 (G66YA-T12) (2010)
YC6G260N-50 (2015)
YC6G270-20 (G46MB) (2010)
YC6G270-30 (G65QA) (2010)
YC6G300-20 (G4704) (2010)
YC6J125Z-T20 (2010)
YC6J125Z-T21 (2015)
YC6J125Z-T22 (2014)
YC6J180-21 (J49D1) (2010)
YC6J190-20 (J41D7) (2010)
YC6J190-T301 (2021)
YC6J210-20 (J42SA) (2010)
YC6J210N-20 (J530C) (2010)
YC6J210N-52 (2018)
YC6J220-50 (2017)
YC6J225N-52 (2014)
YC6J230-20 (J4090) (2010)
YC6J245-30 (J61LA) (2010)
YC6J245-42 (J010N-T1) (2010)
YC6J245-50 (2017)
YC6K (2019)
YC6K440N-50 (2013)
YC6L250L-D30 (L7001) (2010)
YC6L260-30 (2008)
YC6L280-30 (L38MA) (2010)
YC6L280N-52 (2014)
YC6L310-30 (L360A) (2010)
YC6L310-50 (2017)
YC6L330-20 (L33YA) (2010)
YC6L330-30 (L47SA) (2010)
YC6L350-20 (L30JA) (2010)
YC6M220G (M3020) (2010)
YC6M280-20 (M36T1) (2010)
YC6M290N-30 (M2CD1) (2010)
YC6M290N-30 (M2CE1) (2010)
YC6M320N-30 (M2BD1) (2010)
YC6M340-20 (2009)
YC6M340N-30 (M2AE1) (2010)
YC6M360-30 (M6298) (2010)
YC6M390-30 (M6000) (2010)
YC6MK320N-50 (2013)
YC6MK340N-50 (2013)
YC6MK375N-40 (2014)
Схема
>
Не выбрано
J8004-1001000/01 Engine Suspension Assembly
J8004-1002000/01 Cylinder Block Assembly
J8000-1002030/07 Gear Housing Parts
J4000-1003000/11 Cylinder Head & Cylinder Head Cover Assembly
J3200-1004000/01 Piston & Connecting Rod Assembly
J8004-1005000/01 Crankshaft Vibration Damper Assembly
630-1006000A/02 Camshaft Assembly
J3200-1007000/06 Valve Tappet Assembly
J8000-1008100/05 Intake Pipe parts
J8000-1008200/03 Exhaust Pipe Parts
340-1009000/05 Oil Sump Assembly
630-1028000/01 Oil Dipstick Assembly
340-1010000 /05 Oil Collector Assembly
B3000-1011000/05 Oil Pump Assembly
J8001-1012000/02 Oil Filter Assembly
B8700-1013000/08 Oil Cooler Assembly
6105Q-1014000A/03 Breather Part
B7648-1130000/03 Fuel Injection Pump Accessory Assembly
J80G0-1104000/03 Supply System Pipeline Assembly
B7640-1105000/01 Fuel Filter Assembly
J8000-1109000/06 Air Cleaner Assembly
J8004-1111000/01 Injection Pump Assembly
B7648-1130000/03 Fuel Injection Pump Accessory Assembly
J3400-1112000/03 Injector Assembly
J7M00-1118000/01 Turbocharger Assembly
J8000-1201000/09 Muffler Assembly
J8000-1306000/05 Thermostat Assembly
631-1305000/05 Water Drain Cock Assembly
J8004-1307000/03 Water Pump Assembly
396-1308000/02 Fan Assembly
J8004-1303000/04 Water Pipe & Hose Assembly of Radiator
B7648-1600000/04 Power Output Assembly
J8000—3509000/11 Pneumatic Air Compressor Assembly
J8004-3701000/02 Alternator Assembly
B7641-3708000/02 Starter Assembly
B7648-3800000/01 Instrument & Sensors Assembly
A8C02-3904000/01 Nameplate
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
Позиция на иллюстрации
Заводской номер детали
Название детали
1
Q150B0825TF2
Бoлт M8x25
2
Q40308
Шайба 8
3
6105Q-3509013
Шайба
4
L3400-1118301A
Прокладка
5
J8000-1118340
Turbocharger oil return pipe
6
YC208-B01700F
Уплотнительное кольцо 2,65x17
7
J8000-1118240A
Oil inlet pipe welded subassembly
8
J8000-1118270
Pipe clamp subassembly
9
Q1841016TF2
Болт M10x16
10
150-1118031B
Шайба
11
Q1840820TF2
Болт M8x20
12
475D-1118211
Масловпускное соединение
13
L3000-1118031
Соединитель впуска масла
14
G3228-1000092
Exhaust pipe seal camp
15
475D-1118001B
Прокладка турбонагнетателя
16
150-1118001
Шпилька
17
M3000-1008206B
Гайка
18
J7M00-1118100-502
Turbocharger
18
J7M00-1118100-383
Turbocharger
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
