G4709-3701000/06 Alternator Assembly
Каталог запасных частей к технике: Yuchai YC6G260N-50. G4709-3701000/06 Alternator Assembly
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
BAW
Caterpillar
Cummins
DCEC
DongFeng
Doosan
FAW
Great Wall
Hitachi
HOWO
HSW
IVECO
Komatsu
LGMG
Perkins
Raywin
SDEC
Shaanxi
Valmet
Weichai
XINCHAI
YTO
Yuchai
ZF
Алтайдизель
Барнаултрансмаш
ВТЗ
ГАЗ
ЗиД
ЗМЗ
Камский автозавод
ММЗ
СМД
ТМЗ
УМЗ
ЧТЗ
ЮМЗ
ЯЗДА
ЯМЗ
Модель
Не выбрано
YC4108C (D7400) (2010)
YC4108ZG (D7802) (2010)
YC4112ZQ (ZLQ) (2002)
YC4A100-T301 (A515TB) (2021)
YC4A115Z-T20 (2013)
YC4B105Z-T20 (2016)
YC4D (2005)
YC4D120-20 (2008)
YC4D120-20 (D1007) (2010)
YC4D120-30 (D22J1) (2010)
YC4D130-20 (D08FL) (2010)
YC4D130-30 (D2102) (2010)
YC4D140N-50 (2018)
YC4D80-T10 (2009)
YC4D80-T20 (2013)
YC4E135-21 (E02D1) (2010)
YC4E140-20 (E12N2) (2010)
YC4E140-30 (E24FB) (2010)
YC4E150-20 (E05D1) (2010)
YC4E160-20 (E04F1) (2010)
YC4E180-30 (E2100) (2010)
YC4F100-20 (F31D8) (2010)
YC4F115-20 (F30D8) (2010)
YC4F115-30 (F50D1) (2010)
YC4F90-23 (F60LA) (2010)
YC4F90-30 (2008)
YC4F90-30 (F51D1) (2010)
YC4FA130-30 (FC7LA) (2010)
YC4G180-20 (2014)
YC4G180-20 (G0803) (2008)
YC4G180-20 (G0803) (2010)
YC4G180-30 (G2H0B) (2010)
YC4G180N-30 (G2C0H-T1) (2010)
YC4G180N-40 (2014)
YC4G190N-50 (2014)
YC4G200-30 (G2GQA) (2010)
YC4G220-20 (G20JA) (2010)
YC4ND27-90-30 (FD2D1) (2010)
YC6108G (2008)
YC6A240-20 (A3515) (2010)
YC6A240-30 (A68SA) (2010)
YC6A260-20 (A44AB) (2010)
YC6A260-30 (A64YA) (2010)
YC6B125-T10 (B7626) (2010)
YC6B125-T11 (2016)
YC6B125-T20 (2010)
YC6B125-T21 (2016)
YC6G220P-30 (G3FQA) (2010)
YC6G230N-30 (G69MA) (2010)
YC6G240-20 (G52MA) (2010)
YC6G240-30 (2008)
YC6G240-30 (G5BSB-T2) (2010)
YC6G260N-20 (G64HA) (2010)
YC6G260N-30 (G66YA-T12) (2010)
YC6G260N-50 (2015)
YC6G270-20 (G46MB) (2010)
YC6G270-30 (G65QA) (2010)
YC6G300-20 (G4704) (2010)
YC6J125Z-T20 (2010)
YC6J125Z-T21 (2015)
YC6J125Z-T22 (2014)
YC6J180-21 (J49D1) (2010)
YC6J190-20 (J41D7) (2010)
YC6J190-T301 (2021)
YC6J210-20 (J42SA) (2010)
YC6J210N-20 (J530C) (2010)
YC6J210N-52 (2018)
YC6J220-50 (2017)
YC6J225N-52 (2014)
YC6J230-20 (J4090) (2010)
YC6J245-30 (J61LA) (2010)
YC6J245-42 (J010N-T1) (2010)
YC6J245-50 (2017)
YC6K (2019)
YC6K440N-50 (2013)
YC6L250L-D30 (L7001) (2010)
YC6L260-30 (2008)
YC6L280-30 (L38MA) (2010)
YC6L280N-52 (2014)
YC6L310-30 (L360A) (2010)
YC6L310-50 (2017)
YC6L330-20 (L33YA) (2010)
YC6L330-30 (L47SA) (2010)
YC6L350-20 (L30JA) (2010)
YC6M220G (M3020) (2010)
YC6M280-20 (M36T1) (2010)
YC6M290N-30 (M2CD1) (2010)
YC6M290N-30 (M2CE1) (2010)
YC6M320N-30 (M2BD1) (2010)
YC6M340-20 (2009)
YC6M340N-30 (M2AE1) (2010)
YC6M360-30 (M6298) (2010)
YC6M390-30 (M6000) (2010)
YC6MK320N-50 (2013)
YC6MK340N-50 (2013)
YC6MK375N-40 (2014)
Схема
>
Не выбрано
G5B0N-1001000/02 Engine Suspension Assembly
G4R0A-1002000/01 Cylinder Block Assembly
G3E00-1002200/04 Timing Gear Chamber Subassembly
G3Y00-1003000/02 Cylinder Head and Cylinder Head Cover
G3W00-1004000/02 Piston and Connecting Rod
G6899-1005000/01 Crankshaft Vibration Damper Assembly
G3K00-1006000/03 Camshaft Parts
G4200-1007000/05 Valve Train Mechanism Assembly
G4R00-1008100/01 Intake Pipe Parts and G4R00-1008500/02 Intake Connecting Pipe Parts
G3YYA-1008200/03 Exhaust Pipe Parts and G3YYA-1008400/01 Exhaust Pipe Shield Parts
G3R00-1009000/04 Oil Sump Assembly
150-1010000A/05 Oil Strainer
G5A00-1011000/06 Oil Pump Assembly
G4606-1012000/01 Oil Filter
G3R00-1013000/02 Oil Cooler
G3X00-1014000/01 Crankcase Ventilator Assembly
G4623-1028000/01 Oil Dipstick Subassembly
G3K00-1107000/05 Low Pressure Gas Filter Assembly
G4R0A-1107000/01 Low Pressure Gas Filter Assembly
G4R00-1118900/01 Exhaust gas bypass control valve parts
G4R00-1113000/01 Gas Supply Device Assembly
G4R0A-1118000/03 Turbocharger Assembly
LND00-1205000/02 Catalytic Converter Assembly
231-1305000/10 Water Drain Cock
G3LFA-1306000/08 Thermostat Assembly
G3RE2-1307000/02 Water Pump Assembly
G4789-1600000/03 Power Take-off Mechanism Assembly
G3D99-3407000/02 Steering Pump Assembly
G4R0A-3509000/01 Pneumatic Air Compressor Assembly
G4709-3701000/06 Alternator Assembly
G4R00-3705000/02 Ignition System Assembly
E24FH-3708000/01 Starter Assembly
G4R0A-3823000/03 Control System Assembly
E280C-3800000/01 Instruments and Sensors Assembly
D4A00-3904000/02 Nameplate
1
2
2
2
3
3
3
4
5
5
6
6
6
7
7
8
9
9
10
11
12
13
14
15
16
Позиция на иллюстрации
Заводской номер детали
Название детали
1
Q150B1230TF2
Болт M12x30
2
Q40312
Шайба 12
3
Q40112
Шайба 12
4
G4709-3701002
Starter bracket
5
Q350B16
Nut
6
Q40316
Шайба 16
7
Q40116
Шайба 16
8
Q150B16180
Bolt
9
G4709-3701100
Alternator
10
E0218-3701031
Adjusting bolt
11
Q150B1660
Bolt
12
G4709-3701050
Fixed bracket weldment
13
497E-3701032
Блок скольжения
14
Q150B1260TF2
Болт M12x60
15
Q150B1228TF2
Болт M12x28
16
YC80-AV13-1100BG
Strap
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
