5. 340-1004000/03 Piston Connecting Rod Assembly

Каталог запасных частей к технике: Yuchai YC6B125-T21. 340-1004000/03 Piston Connecting Rod Assembly

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано BAW Caterpillar Cummins DCEC DongFeng Doosan FAW Great Wall Hitachi HOWO HSW IVECO Komatsu LGMG Perkins Raywin SDEC Shaanxi Valmet Weichai XINCHAI YTO Yuchai ZF Алтайдизель Барнаултрансмаш ВТЗ ГАЗ ЗиД ЗМЗ Камский автозавод ММЗ СМД ТМЗ УМЗ ЧТЗ ЮМЗ ЯЗДА ЯМЗ

Модель Не выбрано YC4108C (D7400) (2010) YC4108ZG (D7802) (2010) YC4112ZQ (ZLQ) (2002) YC4A100-T301 (A515TB) (2021) YC4A115Z-T20 (2013) YC4B105Z-T20 (2016) YC4D (2005) YC4D120-20 (2008) YC4D120-20 (D1007) (2010) YC4D120-30 (D22J1) (2010) YC4D130-20 (D08FL) (2010) YC4D130-30 (D2102) (2010) YC4D140N-50 (2018) YC4D80-T10 (2009) YC4D80-T20 (2013) YC4E135-21 (E02D1) (2010) YC4E140-20 (E12N2) (2010) YC4E140-30 (E24FB) (2010) YC4E150-20 (E05D1) (2010) YC4E160-20 (E04F1) (2010) YC4E180-30 (E2100) (2010) YC4F100-20 (F31D8) (2010) YC4F115-20 (F30D8) (2010) YC4F115-30 (F50D1) (2010) YC4F90-23 (F60LA) (2010) YC4F90-30 (2008) YC4F90-30 (F51D1) (2010) YC4FA130-30 (FC7LA) (2010) YC4G180-20 (2014) YC4G180-20 (G0803) (2008) YC4G180-20 (G0803) (2010) YC4G180-30 (G2H0B) (2010) YC4G180N-30 (G2C0H-T1) (2010) YC4G180N-40 (2014) YC4G190N-50 (2014) YC4G200-30 (G2GQA) (2010) YC4G220-20 (G20JA) (2010) YC4ND27-90-30 (FD2D1) (2010) YC6108G (2008) YC6A240-20 (A3515) (2010) YC6A240-30 (A68SA) (2010) YC6A260-20 (A44AB) (2010) YC6A260-30 (A64YA) (2010) YC6B125-T10 (B7626) (2010) YC6B125-T11 (2016) YC6B125-T20 (2010) YC6B125-T21 (2016) YC6G220P-30 (G3FQA) (2010) YC6G230N-30 (G69MA) (2010) YC6G240-20 (G52MA) (2010) YC6G240-30 (2008) YC6G240-30 (G5BSB-T2) (2010) YC6G260N-20 (G64HA) (2010) YC6G260N-30 (G66YA-T12) (2010) YC6G260N-50 (2015) YC6G270-20 (G46MB) (2010) YC6G270-30 (G65QA) (2010) YC6G300-20 (G4704) (2010) YC6J125Z-T20 (2010) YC6J125Z-T21 (2015) YC6J125Z-T22 (2014) YC6J180-21 (J49D1) (2010) YC6J190-20 (J41D7) (2010) YC6J190-T301 (2021) YC6J210-20 (J42SA) (2010) YC6J210N-20 (J530C) (2010) YC6J210N-52 (2018) YC6J220-50 (2017) YC6J225N-52 (2014) YC6J230-20 (J4090) (2010) YC6J245-30 (J61LA) (2010) YC6J245-42 (J010N-T1) (2010) YC6J245-50 (2017) YC6K (2019) YC6K440N-50 (2013) YC6L250L-D30 (L7001) (2010) YC6L260-30 (2008) YC6L280-30 (L38MA) (2010) YC6L280N-52 (2014) YC6L310-30 (L360A) (2010) YC6L310-50 (2017) YC6L330-20 (L33YA) (2010) YC6L330-30 (L47SA) (2010) YC6L350-20 (L30JA) (2010) YC6M220G (M3020) (2010) YC6M280-20 (M36T1) (2010) YC6M290N-30 (M2CD1) (2010) YC6M290N-30 (M2CE1) (2010) YC6M320N-30 (M2BD1) (2010) YC6M340-20 (2009) YC6M340N-30 (M2AE1) (2010) YC6M360-30 (M6298) (2010) YC6M390-30 (M6000) (2010) YC6MK320N-50 (2013) YC6MK340N-50 (2013) YC6MK375N-40 (2014)

Схема > Не выбрано B7615-1002000/03 Cylinder Block Assembly B7615-1002200/18 Gear Housing Part B7605-1003000/09 Cylinder Head& Cylinder Head Cover Assembly 340-1004000/03 Piston Connecting Rod Assembly 1640H-1005000/15 Crankshaft and Flywheel Assembly 630-1006000A/02 Camshaft Assembly 330-1007000/08 Valve Tappet Assembly 1640H-1009000/08 Oil Sump Assembly 1640H-1010000/08 Oil Collector Assembly B3000-1011000/06 Oil Pump Subassembly 1640H-1012000/06 Oil Strainer Assembly 1640H-1013000/17 Oil Radiator Assembly 1640H-1600000/03 Flywheel Housing Assembly 311-1014000/05 Breather Parts 311-1008100/07 and B7615-1008500/07 Intake Pipe and Intake Connecting Pipe Part 640-1008200/05 Exhaust Pipe Part 1640H-1201000/07 Muffler Assembly B7615-1104000/08 Fuel Pipeline Assembly B7735-1105000/06 Fuel Filter Assembly B7663-1109000/06 Air Filter Assembly B7606-1111000/08 Fuel Injection Pump Assembly J3400-1112000/04 Injector Assembly 1640H-1303000/13 Water Outlet Pipe Assembly 6105QA-1305000/08 Water Outlet Valve Assembly 340-1306000/02 Thermostat Assembly 1640H-1307000/06 Water Pump Subassembly 310-1308000/04 Fan Parts 340-3509000/12 Pneumatic Air Compressor Assembly B8601-3701000/01 Alternator Assembly 340-3708000/10 Starter Assembly BB600-3904000/01 Nameplate

B3000-1004016

330-1004022-H

330-1004022-L

1

2

3

4

5

6

7

8

Позиция на иллюстрации	Заводской номер детали		Название детали
B3000-1004016	B3000-1004016		Piston ring subassembly
330-1004022-H	330-1004022-H		Узел шатунных вкладышей
330-1004022-L	330-1004022-L		Узел шатунных вкладышей
1	B3000-1004002		First air ring
2	B3000-1004017		Second air ring
3	B3000-1004100		Oil ring assembly
4	340-1004001		Поршень
5	6105Q-1004019B		Поршневой палец
6	Q43038		Стопорное кольцо 40
7	6105QA-1004050D		Узел шатунна
8	330-1004022		Шатунный вкладыш

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
